Stainless Steel Kitcken Sink Inside Polishing Machine -Sink producing line

FOB Price:	10,000.00 USD/Set
Supply Ability:	50 Set/Sets per Month
Payment Terms:	T/T, Western Union

In Stock

Inquiry Now

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Guangdong in China
Packaging Details:	wooden case

Quick Details

After-sales Service Provided: Engineers available to service machinery overseas
Warranty: 12 months
Certification: CE
Power(W): 50KVA
Voltage: 380V
Usage: Sink Polishing
Weight: 800kg
Welding Diameter: 80-1000mm
Welding Mode: automatic polishing
Forming Time: 0.1s-1s
Brand Name: BLUEFLAME
Condition: New
Sink polishing: Sink mirror polishing

Specifications

Product Description

Automatic Washing Sink Inside Polishing Machine

1.General Description

This Equipment is specially designed for Polishing the Stainless Steel Sink Inner Side.When it work,the workpiece turn around by the even speed,and the rolling polishing head clinging and attaching to the inside of sink make the cross movement with the acted direction of workpiece,by this way the workpiece will be polished equably and beautifully. 2.Machine Working Process and Step

Load the Workpiece to the Fixing Jig of Working Table → Start the Machine→ The Polishing Head and Workpiece Start to Go Round and Round Up and Down→ Polishing Until Finish → Automatic Back to the Original Position→Unload the Workpiece.

3.Main Parts List of the Machine

3.1 Air Cylinder and Pressure System;

3.2 Beeline Track;

3.3 Motor Power System

3.4 Polishing Roller

3.5 Special Design Fixing Jig and Table

3.6 Main Body of Machine

3.7 Electric Controlling Box

3.8 Machinery Movement System

4.Main Technical Parameter of Standard Model Machine

4.1 Machine Dimension: L:2000 mm×W:570mm×H:2200mm(Or designed specially basing on the workpiece);

4.2 Polishing Length and Width: 1300㎜×600㎜(Or designed specially basing on the workpiece);
