LREC7210PF-LX PCI 1000Base-LX SM SC Port Fiber NIC Lan Network Adapter (Intel 82545EB Based)

Specifications

LREC7210PF-LX PCI 1000Base-LX SingleMode SC Port Fiber NIC (Intel 82545EB Based)

PCI fiber gigabit connection for your next-generation network

Gigabit fiber adapter eliminates server bottlenecks with industry-leading

Gigabit performance in a PCI bus in 32-bit 33/66MHz and easily integrates into your existing Ethernet infrastructure.

Key Features:

_ Greater distances and noise resistance enabled through fiber optic connection

_ High network performance and flexibility via PCI bus at 32-bit 33/66MHz

_ Alleviate server bottlenecks while increasing uptime through advanced server features

Features:

Intel 82545EB Gigabit Ethernet Controller

Low profile

Widespread Compatibility

Scalable Bandwidth

Adaptive Load Balancing

Intel? Link Aggregation

Fast Ether Channel*

Gigabit Ether Channel*

IEEE 802.3ad

Adapter Fault Tolerance

Mixed-adapter Teaming/Mixed-speed Teaming

Preferred Primary

PCI Hot Plug* and Active PCI*

Standards-based Management

Wired for Management (WfM) 2.0

Desktop Management Interface (DMI) 2.0, SNMP

Specification:

IEEE STANDARD/NETWORK TOPOLOGY:1000 Base-LX

WIRING AND CONNECTORS: Single mode fiber, SC connector

PRODUCT CODE: LREC7210PF-LX

ADAPTER PRODUCT FEATURES

Intel? Single Driver? technology

Intel? Adaptive Technology

Plug and Play Specification Support Easy Installation,

Intel? PROSet II Utility Auto-negotiation, Full-duplex Capable

PCI Buses Supported: 32/66, 32/33

NETWORK MANAGEMENT

Wired for Management (WfM) Baseline v2.0 Enabled for Servers

DMI 2.0 Support, WMI & SNMP-manageable

Offline Diagnostics

Intel? Boot Agent

ACPI Power Management

Wake on LAN*

NOS SOFTWARE SUPPORT

Windows XP 32-bit (64-bit)

Windows Vista 32-bit (64-bit)

Windows Server 2000

Windows Server 2003 64-bit

Windows Server 2008 64-bit

Windows 98/98SE/NT4.0/NT

Windows CE/CE net5.0

NetWare 5.0/5.1/6.0/6.5

OpenUNIX 8.0(Caldera)

UnixWare 7.x

DOS

Novell ODI

FreeBSD 4.7 or 4.x later

Linux 2.2 through 2.6.x kernels

Sun Solaris x86

ADVANCED SOFTWARE FEATURES1

Adapter Fault Tolerance

Adaptive Load Balancing

Fast Ether Channel* (when used with a capable switch)

Gigabit Ether Channel* (when used with a capable switch)

Intel? Link Aggregation (when used with a capable switch)

IEEE 802.3ad (when used with a capable switch

802.1p

PCI Hot Plug* and Active PCI*

802.1Q VLANs

802.3x Flow Control

TCP Checksum Offload

802.1p, Intel? Priority Packet

Adaptive Performance Tuning

TECHNICAL FEATURES

Data Rate(s) Supported Per Port: 1000Mbps

Onboard Memory: 64KB

Interrupt Levels: INTA

IEEE Support: 802.2 & 802.3z

Data Path Width: 32-bit

Consumption Operating Temperature Operating Humidity:

Hardware Certifications: CE, FCC, ROHS

Data Transfer Mode: Bus-master DMA

Controller – Processor: Intel? 82545EB

Typical Power Consumption: 1A @+5VDC

Operating Temperature: 0-55°C

Operating Humidity: 85% at +55°C

SECURITY FEATURES

IPSec Standard (Windows 2000)

IPSec Standard (Windows NT 4.0)

With Intel? Packet Protect

Intel? 82545 Controller with Integrated

Encryption Co-processor

Encryption2

3DES (168 bit) Encryption in software

Authentication Algorithms in software

SHA-1

MD5

Authentication Method Preshared Key Entrust/PKI*

Ordering Information:

PS: The above details are just for reference, if there are any changes, no inform will have.
