chromium carbide overlay pipe

FOB Price:	160.00 - 500.00 USD/Meter
Supply Ability:	30,000 Meter/Meters per Year
Shipping:	SHANGHAI PORT
Payment Terms:	L/C, T/T

In Stock

Inquiry Now

Related products from verified members

Connect Water Exploring Drill Pipe

Price:

Min. Order:
low carbon steel tube

Price:

Min. Order:
steel pipe

Price:450.00-1000.00 USD/Piece

Min. Order:1 Piece
Precision Seamless Steel Tube

Price:

Min. Order:5 Metric Ton
Mechanical Lined Pipe

Price:100.00-1,000.00 USD/Box

Min. Order:100 Boxes

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Jiangsu in China
Packaging Details:	IN PALLET

Quick Details

Alloy Or Not: Is Alloy
Special Pipe: Thick Wall Pipe
Surface Treatment: WELDING
Certification: ISO 9001
Technique: Hot Rolled
Application: Oil Pipe
Secondary Or Not: Non-secondary
Section Shape: Round
Outer Diameter: 150-3000 mm
Thickness: 4-14 mm
Grade: Cr-Mo alloy,CrNi alloy
Grade: 12Cr1MoVG,Cr17Ni8
Standard: ASTM
Standard: ANSI A213-2001
manufacturer: YAOYU
materials: VAUTID
hardness: HRC 58-62

Specifications

Zhangjiagang YaoYu Wear Resistant Materials Co.,Ltd supply high hardness wear resistant steel pipe with high quality, with nearly 10 years experience in designing and

manufacturing different size hardfacing steel products for customers, and can offer the best wear solution according to the actual working conditions.

wear resistant composite steel pipe is a kind of new type high wear resistant composite material, it uses automatic CNC open arc hardfacing process and has a high

chromium wear resistant alloy layer welded inside the seamless steel pipe

The weld material is with following chemistry: Carbon 4.2~5.45% , Cr 25.3~30%, Si 0.7~1.5%, Mn 0.2~1%, Ni 0.1~0.4%, B 1~1.5%, Fe-balance

wear resistant steel pipe is also known as chromium carbide overlay pipe, which is suitable for mining equipment, cement equipment, metallurgical equipment, electrical

equipment manufacturing and fabrication industries with excellent wear resistance, excellent impact resistance, excellent deformation capability and welding ability.
1. OD: above 150mm
2. Specifications are : 6+4,6+5,6+6,8+4,8+5,8+6,10+4 etc. (base layer+ hardfacing layer)
3. Hardness: HRC 58-62

Generally, functionality of its wear resistance has the following statistics:

1.20- 25 times harder than low carbon steel pipe;
2.1.5-2.5 times harder than as-cast high chromium steel pipe;
3.5-10 times harder than tool steel pipe;
4.5-20 times harder than high manganese steel pipe

Advantages of wear resistant steel pipe:
1. Can be cut, welded, bend and formed
2. Cost effective
3. Long service life and reduce downtime
4. High hardness, good abrasion & impact resistant
5. Wide applications
