DFP Thermoforming Packaging Machine SafeBuy Supplier Member

Supply Ability: 10 Unit/Units per Month
Shipping: Wthin 45-60 days
Payment Terms: L/C, T/T
Export Markets: North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin: Shanghai in China
Packaging Details: Export Wooden Cases

Quick Details

  • Processing Type: Plastic Thermoforming Machine
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Warranty: One year
  • Certification: CE
  • Weight: 1300--2100kg
  • Power(W): 10--20kw
  • Model Number: DFP
  • Brand Name: Jornen
  • Condition: New

Specifications

This series of Thermoforming Packaging Machine has been designed to pack food and medical products, capable of both flexible and rigid packaging..
Optional vacuum and gas flushing systems to create (MAP) modified atmosphere packages are available.
They are constructed in corrosion resistant materiales and a full stainless steel structure (AISI 304).

Main Technical Parameters:
Model:                                  DFP320                         DFP420                          DFP520
Max. Output:                         15/min.                         15/min.                         15/min.
Sealing Material Width:           322mm                          422mm                         522mm
Forming Material Width:          292mm                          392mm                         492mm
Machine Power:                      10Kw                            13Kw                             20Kw
Machine Dimension:                5100X900X1800            6150X1200X1900         6200X1400X1900
Machine Weight:                     1300Kg                        1700Kg                         2100Kg
