Hebei Xing Kuan Wire Mesh Products Co., Ltd.
China Manufacturer with main products: Razor Barbed Wire, Chicken Wire Netting, Gabion Box, Chain Link Fence, Gabion Mesh, High Zinc Coating Gabion, Stone Gabion, Gabions Mesh |
Quick Details
- Razor Type: Cross Razor
- Type: Barbed Wire Coil
- Surface Treatment: Galvanized
- Material: Steel Wire
Specifications
Razor barbed wire or razor wire mesh is a mesh of metal strips with sharp edges whose purpose is to prevent passage by humans. While razor wire is much sharper than the standard barbed wire, it is not actually razor sharp. Even so, the multiple blades of a razor barbed wire fence are designed to inflict serious cuts on anyone attempting to climb through and therefore have a strong psychological deterrent effect. In many high-security applications, razor wire mesh supplanted barbed wire, which could be circumvented relatively quickly by humans without tools, while penetrating razor wire barriers without tools is very slow and difficult, giving security forces more time to respond.
We can produce razor type barbed wire in single loop, cross type or concertina, welded type and flat type.
* Single Loop Razor Barbed Wire
Straight from spiral razor barbed wire. Made of hot-dipped galvanized steel sheet or stainless steel sheets. It is easy to install while saving the cost. Spiral razor wire is installed without clips, it can be installed in its natural loops on walls, which looks beautiful and practical.
* Cross Type or Concertina Razor Barbed Wire
The contiguous two razor wire cross and fastened by iron clips, we call it double loops or cross type razor barbed wire and it is also called concertina razor barbed wire. Concertina razor barbed wire is a new defencing product which is fetched from abroad. Sharp razor barbed wire has a snake-shaped, constituted by fastened double strand razor wire. Frightening anyone who want to get close to the fence. Actually, people will be hurt once get across it. Concertina cross type razor barbed tape wire enjoys good appearance, practical use and can ensure stronger protection.
Cross type razor barbed wire has been widly used in airport, key military sites, border line, prison, government, bank, bounding wall of villa, highway, fence of railway and etc. In many countries. It is easily and expediently installation, welcome by army and police.
* Flat Razor Barbed Wire
Flat razor wire fence is the new application for razor wire. It is practicable and beautiful. It can be used together with the straight type razor barbed wire to form protecting wall. Razor barbed wire in flat wrap type is mainly used in warehouse, stock farm, farm, mine, prison, national defense, etc.
Reference Number
Thickness
Wire Diameter
Barb Length
Barb Width
Barb Spacing
BTO-10
0.5 ± 0.05
2.5 ± 0.1
10 ± 1
13 ± 1
26 ± 1
BTO-12
0.5 ± 0.05
2.5 ± 0.1
12 ± 1
15 ± 1
26 ± 1
BTO-18
0.5 ± 0.05
2.5 ± 0.1
18 ± 1
15 ± 1
33 ± 1
BTO-22
0.5 ± 0.05
2.5 ± 0.1
22 ± 1
15 ± 1
34 ± 1
BTO-28
0.5 ± 0.05
2.5 ± 0.1
28 ± 1
15 ± 1
45 ± 1
BTO-30
0.5 ± 0.05
2.5 ± 0.1
30 ± 1
18 ± 1
45 ± 1
Outer diameter
No. of loops
Standard length per coil
Type
Notes
450mm
33
7m-8m
CBT-65
Single coil
500mm
41
10m
CBT-65
Single coil
700mm
41
10m
CBT-65
Single coil
960mm
54
11m-15m
CBT-65
Single coil
500mm
102
15m-18m
BTO-12,18,22,28,30
Cross type
600mm
86
13m-16m
BTO-12,18,22,28,30
Cross type
700mm
72
12m-15m
BTO-12,18,22,28,30
Cross type
800mm
64
13m-15m
BTO-12,18,22,28,30
Cross type
960mm
52
12m-15m
BTO-12,18,22,28,30
Cross type
