Split Mountain Machine & Eqiupment Co., Ltd.
China Manufacturer with main products: ORC Screw Generator, Steam Screw Generator, Compressor, Jumbo, Vacuum Pump |
Jumbo drill for underground mining or tunnelling with three arms
| FOB Price: | 828,000.00 - 830,000.00 USD/Set |
|---|---|
| Supply Ability: | 2,000 Set/Sets per Quarter |
| Shipping: | 80-90 days after receiving your deposit |
| Payment Terms: | T/T |
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Shanghai in China |
Quick Details
- After-sales Service Provided: Engineers available to service machinery overseas
- Warranty: 12 months+1 month after delivery or 1 year after using
- Certification: CE+ISO+ASME
- Weight: 32000 kg
- Dimension(L*W*H): 14300*3200*3800 mm
- Power(W): 195 kW
- Voltage: 380V 50Hz 3 Phase
- Usage: Ore
- Model Number: ZD338
- Brand Name: SMME
- Power Type: Electric
- Type: Face drilling rig
- Condition: New
Specifications
Suitable for underground mining and tunneling
Specifications
??ROCK DRILL
DZYG38B
Weight 150 kg
Impact rate 40-60 Hz
Rotation torque 500 N.m
Hole diameter 45-102mm
??Booms
BH1
Booms extension 1600 mm
Lifting Height for two side Booms 2000 mm
??Carrier
VOLVO TAD721-V1
Turning radius 9500 mm
Power 195 kW
??Feed
AT1531
Feed length 5525 mm
Feed extension 1600 mm
??Hydraulic platform
Extension 4000mm
Loading capacity Max. 500 kg
