Yanshancounty Fengliyuan Pipe Fittings Equipment Manufacture Co., Ltd.

Home >Products Catalog > carbon steel elbow machion > 4-12 inch 325mm carbon steel induction heating hydraulic press machine

4-12 inch 325mm carbon steel induction heating hydraulic press machine

FOB Price:	20,000.00 - 30,000.00 USD/Set
Supply Ability:	100 Set/Sets per Year
Shipping:	Tianjin
Payment Terms:	L/C, T/T, Western Union, MoneyGram

In Stock

Inquiry Now

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Hebei in China
Packaging Details:	no packing

Quick Details

The Main Technical Parameters of The Machine

1 The oil cylinder:ID 360mm, the rod:Ф260mm , the effective trip: 6.5m, pressure: 21Mpa,2 bars

The maximum thrust of the 2 cylinders:420 tons; The working speed: 0—80cm/min ,

The max backward speed: 380cm/min.

2 The pump station:

63scy-plunger pump :2 set, 18.5KW Motor: 2sets (the main working pump)

PV2R13-23-116 double vane pump 1 set,15kw motor 1 set.

The hydraulic valve is integrated oil rout, hydraulic back fork gate. Automatic feeding. an adjustable shelf (height and width) for the heating coils

3. The frame for the machine body: 30# channel steel, welded with 43kg steel rail

4 The panel for the main engine: welded with 40-50mm medium steel sheet.

5 Distribution cabinets, operation box1set

6 Intermediate-frequency power (power 600KW 380v, 220v, 50/60Hz)
