Home >Products Catalog > pipe expanding machine > hydraulic machine for theraml expanding new or used carbon steel pipe and tube

hydraulic machine for theraml expanding new or used carbon steel pipe and tube

FOB Price:	30,000.00 - 120,000.00 USD/Set
Supply Ability:	100 Set/Sets per Year
Shipping:	Tianjin
Payment Terms:	L/C, T/T, Western Union, MoneyGram

In Stock

Inquiry Now

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Hebei in China
Packaging Details:	no

Quick Details

After-sales Service Provided: Engineers available to service machinery overseas
Warranty: 12 months
Certification: ISO, CE
Weight: 30 Tons
Dimension(L*W*H): 13*2*1
Power(W): 500 KW
Voltage: 380
Model Number: YKG-4
Brand Name: Fengliyuan
Production Capacity: 50 Tons per day
Application: Energy Supply Pipe
Pipe Material: Carbon Steel
Type: Pipe Production Line
Condition: New
power: hydraulic
dreiver: cylinder
heating: medium frequenc
model: customized

Specifications

The Main Technical Parameters of The Pipe Expanding Machine

1. The oil cylinder: Ф 300mm,the rod: Ф 230mm, the effective trip: 6.5m, pressure: 21Mpa,2 bars

The maximum thrust of the 2 cylinders: 300 tons; The normal speed: 0—100cm/min ,

The max backward speed: 300cm/min.

2. The pump station:

63scy-plunger pump :2 set, 18.5KW Motor: 2 sets (the main working pump)

PV2R13-16-94 double vanes pump: 1 set, 15KW motor: 1set (for fast moving forward and returning,etc)

3. The hydraulic valve is integrated oil rout, hydraulic black fork gate, automatic loading.

4. The frame for the main engine: 25# channel steel, welded with 43kg steel rail

5. The panel for the main engine: welded with 25-30mm medium plate

6. distribution cabinets, operation box1set

7. Intermediate-frequency power (power 600KW 380v, 220v, 50Hz)

The works and the scope of supply of the supplier

1. Design and manufacturehydraulic pushing pipe expanding machine

2. Guide to install the equipment as the equipment arrives at the factory of buyer

3. Debugging and test run the equipment

4. Main machine part, hydraulic pump station, heating system.

5. A. frame for the main engine: 1 piece, hydraulic pump station: 1 set,

distribution ark 1set, front and back fork door: 3 blocks . the feeding and loading shelves, the feeding lifter.

B. Intermediate-frequency electric ark: 1 piece,

reactor, capacitor: 1 set, water cable: 2 (L=2500mm)

6. The equipment foundation drawing, hydraulic principle drawing, electrical diagram, each with 1 coppy
