200kw Natural Gas/Biogas Generator

Shipping:	FOB Qingdao
Payment Terms:	L/C, T/T

Inquiry Now Start Safebuy Order

ECVV Safebuy Services

According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
Safebuy Service Guarantee

Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Shandong in China
Packaging Details:	seaworthy package

Quick Details

200kw natural gasbiogas generator 200kw natural gas/biogas generator specification

Generating set general Model		200GFT
Structure		Integral
Exciting method		AVR Brushless
Rated Power (kW)		200
Rated Current(A)		360
Rated Voltage(V)		400/230
Rated Frequency(Hz)		50
Rated Power Factor		0.8 LAG
No load voltage setting range		95%-105%
Steady state voltage regulation rate		1%
Transient state voltage regulation rate		-15%+20%
Voltage fluctuation rate		3s
Steady state frequency regulation rate		0.5%
Transient state frequency regulation rate		10%
Frequency stabilization time		5s
Line-voltage waveform sinusoidal distortion rate		2.5%
Gas Engine	Model	ND119D20TL
	Type	V type 4 stroke, electric control ignition, pre-mixed lean burn, turbocharged after cooled
	Cylinder number	6
	Bore x Stroke (mm)	132X145
	Total displacement (L)	11.9
	Rated Power (kW)	216
	Rated Speed (r/min)	1500/1800
	Speed Regulation Mode	Electrical
	Starting Mode	Electrical
	Fuel type	Natural gas/biogas
Overall dimension (L x W x H)(mm)		2650X1460X1880
Net weight (kg)		2250
