Cooling production edible oils and fat oils BUSCH industrial box type water cooled chiller

FOB Price:	13,440.00 - 15,260.00 USD/Set
Supply Ability:	10,000 Set/Sets per Month
Shipping:	Shanghai sea port,China
Payment Terms:	L/C, T/T, Western Union

In Stock

Inquiry Now

Related products from verified members

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Shanghai in China
Packaging Details:	Plywood packaging

Quick Details

After-sales Service Provided: Engineers available to service machinery overseas
Warranty: 1 Year/2 Years/3 Years
Certification: ISO
Weight: 830 kg
Dimension(L*W*H): 1950mm*1250mm*1600mm
Voltage: 380V/415V/440V/-3P-50Hz/60Hz
Cooling Capability(kw): 55.3 kW / 15.7 RT
Model Number: BBP-20DA
Brand Name: BUSCH
Type: Air-Cooled
Condition: Non-standard product and design:Acceptable
Cooling capacity: 55.3 kW / 15.7 RT
Whole unit power input: 19.3 kW
Whole unit current power: 35.3 A
Compressor type: Fully enclosed scroll compressor
Compressor quantity: 2 set
Condenser fan power input: 1.14 kW
Condenser fan current power: 3.0 A
Chilled water flow: 158L/min
Chilled water tube diameter: DN 40
Chilled water pump input power: 1.50 kW

Specifications

Box-type industrial chillers are the units of which applicable cooling(heating) medium is air or water in summer(winter), and their secondary refrigerant is water. They are widely used in various equipments and cooling models of plastics, electronics , food , pharmaceutical , electroplating , chemical , printing , coating , laser and CD-ROMs and other industrial.

HS Code:8418699090
Cooling production edible oils and fat oils BUSCH industrial box type water cooled chiller
Model:BBP-20DA
Cooling capacity:55.3 kW / 15.7 RT
Whole unit power input:19.3 kW
Whole unit current power:35.3 A
Compressor type: Fully enclosed scroll compressor
Compressor quantity:2 set
Condenser fan power input:1.14 kW
Condenser fan current power:3.0 A
Chilled water flow: 158L/min
Chilled water tube diameter:DN 40
Chilled water pump input power:1.50 kW
Chilled water pump lift head:24 mH2O
Water Tank: 270L
Size:1950mm*1250mm*1600mm
Weight:830 kg
Power standard:380V/415V/440V/-3P-50Hz/60Hz
Refrigerant:R22/R407C/R134a
Non-standard product and design:Acceptable
