Specifications
1. Concrete Mixer Truck
SPRING Concrete Mixer Truck is strong well designed equipment meant for transporting concrete / mortar from concrete batching plant directly to the place where it is to be poured, effectively delay concrete coagulations, avoid concrete stratification and eduction, and ensures construction quality and speed.
SPRING Concrete Mixer Truck has a wide range of application especially for mass concreting works like Construction of Canals, Bridges, Highways, Dams, Multistoried & Industrial Buildings, Factories, and Airports for ready mixed Concrete Works.
SPRING Concrete Mixer Truck overseas hot-sale includes two models such as 9m3, 10m3and any tailor-made-for-mixer-truck special chassis both at home and abroad as supporting part are available to choose.
2.Details
|
(Power-Volume) |
336-9 |
345-9 |
336-10 |
345-10 |
|
|
Vehicle Announcement |
BJ5254GJB-S |
BJ5254GJB-S |
BJ5254GJB-S |
BJ5258GJB-1 |
|
|
Vehicle Size (Length*Width*Height)(mm) |
9050×2495×3950 |
9050×2495×3950 |
9050×2495×3950 |
9050×2495×3920 |
|
|
Max. Weight(kg) |
25000 |
25000 |
25000 |
25000 |
|
|
Curb Weight(kg) |
13240 |
13240 |
13240 |
13240 |
|
|
Wheel Base(mm) |
3575+1350 |
3575+1350 |
3575+1350 |
3575+1350 |
|
|
Cabin |
ETX |
ETX |
ETX |
ETX |
|
|
Drive Type |
6×4 |
6×4 |
6×4 |
6×4 |
|
|
|
model |
WP10.336 |
WP10.336 |
WP10.336 |
ISMe345 30 |
|
Rated Power Kw/(r/min) |
247/336(2200) |
247/336(2200) |
247/336(2200) |
254/345/1900 |
|
|
Emission |
euro-Ⅲ |
euro-Ⅲ |
euro-Ⅲ |
euro-Ⅲ |
|
|
Hydraulic Pump |
model |
A4VTG90 |
A4VTG90 |
A4VTG90 |
A4VTG90 |
|
Hydraulic Motor |
model |
AA2FM80 |
AA2FM80 |
AA2FM80 |
AA2FM80 |
|
Reducer |
mode |
P4300 |
PMB6.5SP |
P4300 |
P4300 |
|
Drum Geometric Volume(m3) |
16 |
16 |
17 |
17 |
|
|
Charge Speed(m3/min) |
3 |
3 |
3 |
3 |
|
|
Inclining Angle |
12° |
12° |
12° |
13.5° |
|
|
type |
Air Pressure |
Air Pressure |
Air Pressure |
Air Pressure |
|
|
Volume (L) |
360 |
360 |
360 |
360 |
|
3. Principal components of the concrete mixer truck
1. Hydraulic System: hydraulic pump, hydraulic motor.
2. Drivetrain System: reductor.
3. Control System.
4. Mixing System.
5. Cleaning System.
4.Advantages of SPRING concrete mixer truck
1.High-intensity drum material.
2.Featuring better wear-resistance and long service life.
3.Optimized mixing blades.
4.Low material residue.
5.High-quality parts.
6.Excellent performance and convenient operation.
7.Imported original hydraulic system(Bosch Rexroth Brand).
8.CF or PMP brand reducer.
5. Packaging＆Delivery
|
Packaging : |
exporting standard package,or as customer's requirement |
|
Delivery : |
30 days after receiving consignee's deposit. |
