Jinan Maohong Industry & Trade Co., Ltd.
China Manufacturer with main products: CNC Router, Laser Engraving Machine, Woodworking Machinery, Stone Carving Machine, Plasma Cutting Machine, CNC Engraver, Co2 Laser Engraver |
16th
JX-ATC1530L JIAXIN Vacuum table cnc wood router with ATC
| FOB Price: | 13,000.00 - 26,000.00 USD/Set |
|---|---|
| Supply Ability: | 30 Set/Sets per Month |
| Shipping: | Within 25 days after received your deposit FOB Qingdao |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Shandong in China |
| Packaging Details: | Steel frame and plywood box |
Quick Details
- After-sales Service Provided: Engineers available to service machinery overseas
- Warranty: 12 months
- Certification: CE,CIQ,QC,SGS,SAI
- Weight: 3000KG
- Dimension(L*W*H): 2.25*3.0*1.8m
- Power(W): 7.5KW
- Voltage: AC380V/50Hz others optional
- Model Number: JX-ATC1530D
- Brand Name: JIAXIN
- CNC or Not: CNC
- Condition: New
Specifications
JX-ATC1530L JIAXIN Vacuum table cnc wood router with ATC
|
Model
|
JX-ATC1530L
|
|
X . Y Axis working area
|
1500X3000mm
|
|
Z Axis working area
|
200mm
|
|
Table Structure
|
Vacuum table
|
|
Repeatability
|
0.025(+/-mm)
|
|
Max Cutting Speed
|
30m/min
|
|
Rapid Traverse
|
45m/min
|
|
Spindle power rate
|
7.5KW(HSD wind-cooled)
|
|
Spindle rotating speed
|
0-18000rpm
|
|
Command
|
G code*. u00*. Mmg*plt
|
|
Work Mode
|
Servo motor
|
|
Power
|
AC380V/50Hz
|
|
Net weight
|
2500kg
|
|
Gross weight
|
2800kg
|
Suitable Industry
Suitable for high-volume processing of non-ferrous metal sheet, Such as aluminum veneer, aluminum composite panel,
copper, PVC board, acrylic, insulation materials, wood and composite panels such as sheet processing, cutting, slotting,
engraving, milling, etc.
copper, PVC board, acrylic, insulation materials, wood and composite panels such as sheet processing, cutting, slotting,
engraving, milling, etc.
Performance Characteristics
1.Italy Columbus Automatic Tool Changer Spindle. All steel structure, to stress treatment, precision machining.
2.Guides: X, Y axis use the TAIWAN PMI linear guides. X, Y axis drive: both use high-precision rack and pinion drive,
fast running speed. Y axis dual-motor synchronous drive. Z axis drive: A high-precision ball screw drive with low coefficient
of sliding friction force is small, fast run smooth.
fast running speed. Y axis dual-motor synchronous drive. Z axis drive: A high-precision ball screw drive with low coefficient
of sliding friction force is small, fast run smooth.
3.Towline and cables are Germany IGUS flexible cable. Table Surface: Vacuum table with 6 vacuum zones.
4.Software: compatible of all CAD/CAM software. With vacuum table and dust collector.
Guarantee & aftersales service
Guarantee for one year, 24-hour technical support by email or calling.
User-friendly English manual and Video CD for machine using and maintaining.
