Home  >Products Catalog > CNC Router > Wood cnc router furniture marking machine

Wood cnc router furniture marking machine

FOB Reference Price: $ 6750
Wholesale: 1 Sets
Supply Ability: 100 Set/Sets per Month
Shipping: QINGDAO PORT
Payment Terms: T/T, Western Union
Update Time: 2017/11/23

Related products from verified members

Export Markets: North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin: Shandong in China
Packaging Details: WOODEN BOX

Quick Details

  • After-sales Service Provided: Engineers available to service machinery overseas
  • Warranty: 1 year
  • Certification: CE
  • Weight: 1150kgs
  • Dimension(L*W*H): 1500*3000mm
  • Power(W): 7KW
  • Voltage: 220V
  • Model Number: NC-D1212
  • Brand Name: NICE-CUT
  • CNC or Not: CNC
  • Condition: New
  • Type: woodworking cnc router

Specifications

Specifications

Wood cnc router furniture marking machine
1,1500X3000mm
2,Vacuum pump & vacuum table
3,Easy control and operation
4,CE,FDA

Wood cnc router furniture marking machine



APPLICATION:

1,Woodworking industry:

Three dimensional wave plate processing,cupboard doors,wooden doors,window processing,vedio game cabinets and panels,computer table and furniture auxiliary processing.

2,Advertising industry:

Advertising signs,logo production,acrylic,plastic cutting,production of decorative materials,forming system module,etc.



Specifications:



NO.

Discription

Parameter

1

X,Y,Z Working Area

1500x3000x200mm

2

Table Size

1640×3540mm

3

X,Y,Z Traveling Positioning Accuracy

±0.03/300mm

4

X,Y,Z Repositioning Positioning Accuracy

±0.05mm

5

Lathe Structure

Welded Strucutre

6

X, Y Structure

Gear Wheel Transmission, Shaft Linear Bearings

7

Z Structure

Ball Screw, Shaft Linear Bearings

8

Max.Consume power

6.5Kw

9

Max.Speed

0-32000mm/min

10

Max.Working Speed

0-20000mm/min

11

Spindle Power Motor

3.0KW water cooling Spindle

12

Spindle Speed

0-18000RPM

13

Working Mode

Stepper

14

Working Voltage

AC380V,3PH/50/60Hz,3PH

15

Command

G Code, *uoo, *mmg, *plt

16

Operating System

DSP System (NC Studio control system option)

17

Interface

USB

18

Flash Memory

128M

19

Collet

ER25

20

X,Y Working Delicacy

<0.01mm

21

Software

Ucancam /Artcam software

22

Running Circumstance

Temperature: 0°C~45°C
Relative humidity: 30%~75%

23

Packing Size

Seperated: 3200X1950X1404mm
Integrated: 3200X1950X1950mm

24

Net Weight

900KG

25

Gross Weight

1150KG

All parameters above subject to change without prior notice





Features:


1. Upgraded spindle
 We adopt spindle with the power range from 4 to 12 horsepower,which is with higher precision bearings and DC brushless motors.

Spindle is the crucial part of CNC router, higher quality spindle could bring you more benefit since it can save your time and increase your productivity. Both HSD and Colombo spindles are available.
2. Dust collection System
NICECUT values working environment protection when offering CNC router. It can eliminate the airborne dust completely. Double cloth bag with 3kw motor can assist your job perfectly!
3. Vacuum hold down system

There are different power and price level pumps for matching your needs!



SAMPLE PHOTOS:

Woodcncrouterfurnituremarkingmachine
Woodcncrouterfurnituremarkingmachine
