Shenyang Aero Space Xinyang Quick Freezing Equip. Manuf. Co., Ltd.
China Manufacturer with main products: Freeze Dryer, Vacuum Fryer, Quick Freezer |
vacuum Lyophilizer
| Supply Ability: | 100 Set/Sets per Year |
|---|---|
| Shipping: | 60days |
| Payment Terms: | L/C, T/T |
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Liaoning in China |
| Packaging Details: | wooden package |
Quick Details
- After-sales Service Provided: Engineers available to service machinery overseas
- Warranty: 12 month
- Certification: ISO9001
- Power(W): 115kw
- Voltage: 380V
- Type: Dryer
- Model Number: lg200
- Brand Name: xinyang
- Condition: New
Specifications
The main technical data of LG-200
Heating plate area 200m2
Product loading capacity 5.4m3
Heating type Both side radiation
Heating plate temperature regulating range 30~130℃
Nominal H2O sublimation capacity Max. 440kg/h
Nominal working pressure > 50Pa
Ultimate pressure 20Pa
Time for pumping down 15min
Refrigeration capacity needed(-40℃evaporating) 320kw
Steam consumption peak value (0.7MPa) 690kg/h
Power 115kw
Product capacity 2400kg/batch (Raw material)
Trays numbers 480pcs
Trolleys 8pcs
Trays dimension 560*680*35mm
Advantages
1. Efficiency of Heating plates
The material of heating plates are aviation aluminum with anodized on the surface, over 100% heat release to the product by radiation way, keep good heating uniformity everywhere.
2. Alternate Vapor trap
Double vapor trap located under the heating plates inside drying chamber, Just trap 1 condensates water vapor until it can't catch vapor any more, then trap 2 starts condensation function, and trap 1 will begin to be defrost ice for another condensation cycle.
3. Continous De-icing
When the trap 2 begins to catch water vapor, the trap 1 begins to be defrost ice on the tube bundle during product drying, after de-icing, the empty and smooth tubes for another condensation cycle.
4. Automatic control system
Advanced intelligent control system keeps whole system stable and reliable running for a long term, furthermore, Simple operation method can be much easier to master.
