Jinan Shengrun Machinery Co., Ltd.
China Manufacturer with main products: Screw Extruders, Dryers, Fryers/Flavoring Machines, Core Filling Snack/Puffed Leisure Food Production Line, Corn Flakes/Breakfast Cereals... |
Home
>Products Catalog > snacks food processing line > Twin screw automatic puff snacks food extruder/snack food machine
Twin screw automatic puff snacks food extruder/snack food machine
| FOB Price: | 4,999.00 - 49,999.00 USD/Set |
|---|---|
| Supply Ability: | 20 Set/Sets per Month |
| Shipping: | port:Qingdao 30 working days |
| Payment Terms: | L/C, T/T |
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Shandong in China |
| Packaging Details: | Inside package is protective film, outside package is wooden/plywood case, which is seaworthy. |
Quick Details
- After-sales Service Provided: Engineers available to service machinery overseas
- Warranty: 1 year
- Certification: ISO, CE, SGS,BV
- Dimension(L*W*H): 17000*1300*2200mm
- Weight: As final production line
- Power(W): 74KW
- Voltage: 220/380/415/440V, etc
- Application: snack food
- Model Number: TSE65
- Brand Name: Shengrun
- Condition: New
- Output: 120-150kg/hr
- Mainbody material:: Stainless steel
- Extruder type: Twin-screw extruder
Specifications
Brief introduction
The snacks food processing line can do the works of raw materials preparation, extrusion, oven dry, and flavoring at a time , which is high automation degree. This production line has the advantages of more machine choice, flexible and diverse configurations, wide range of raw materials application, numerous in products variety and easy operation. It can make the puffed food, such as cheese balls, corn curls, corn sticks, coco pops, cereal and pellets. They are the perfect leisure food for consumers.
Details
1. The model is TSE65-III, the output is 120-150kg/h.
2. Extruder screws quantity is two.
3. The main body material is stainless steel, which is easy to be cleaned.
4. The screws material is 38CrMoAl, which is .
5. The processing line needs two workers to operate.
6. We advice the plant area is no less than 100 square meters, the length is no less than 20 meters.
7. Process flow: (Raw material)---Conveying---Mixing---Extruding---Conveying---Drying---Flavoring --- (packing)
8. Equipments: Mixer---Screw Conveyor---Extruder---Hoister---Dryer---Hoisting and flavoring machine---Oil sprayer---Roller--- (Packing machine)
9. The temperature and rotating speed can be controlled and adjusted.
10. The processing line has self-cleaning function.
Parameters
|
Equipment name |
Mixer |
Screw Conveyor |
Extruder |
Hoister |
|
Model |
BFJ-1 |
LXTS |
TSE65 |
TSJ |
|
Total power (kw) |
3 |
0.75 |
35 |
0.75 |
|
Actual Power (kw) |
2 |
0.5 |
22 |
0.55 |
|
Output (kg/h) |
20kg/batch |
300 |
120-150 |
160 |
|
Size (m) |
1.0×0.7×1.3 |
2.7×0.8×2.2 |
2.6×0.9×1.9 |
2.7×0.6×1.9 |
|
Equipment name |
Dryer |
Hoisting and Flavoring Machine |
Oil Sprayer |
Roller |
|
Model |
KX-3 |
TSTW |
PYJ |
GT |
|
Total power (kw) |
27 |
1.12 |
4 |
0.75 |
|
Actual Power (kw) |
18 |
1 |
3 |
0.5 |
|
Output (kg/h) |
150 |
300 |
200 |
200 |
|
Size (m) |
5.4×1.3×2.2 |
1.5×0.7×1.5 |
1.0×0.6×0.8 |
2.3×0.8×1.3 |
Note: All of the motors are based on the electricity of 380V/50Hz/3 phases. If your location three phase electricity voltage is different from it, we have to change the motors. The price will be increased.
Service
1 The warranty period is one year.
2 Our service is turn-key mode, which includes installment, debugging and train.
3 Supply quick-wear part and general tool.
4 Supply the basic formula of raw materials.
Don't hesitate to contact us. Our team from pre-sale service to-after-sale service will prove that your choice is worth it!
