Monofilament Polyester Filter Mesh

Specifications

Specifications

polyester mesh
1.monofilament polyester mesh
2.free samples
3.China supplier
4.manufacturer provide best price

Monofilament Polyester Screen Printing Mesh /Fibric/Cloth

monofilament polyester screen printing mesh/silk bolting cloth/mesh fabric

high tension silk screen printing mesh/ silkscreen printing mesh

Plain Weave, Low Elongation

Excellent Tear Resistance

Free Samples

Polyester Monofilament Printing Mesh/ Silk Printing Mesh

Polyester Printing Mesh/Monofilament Polyester Mesh/Monofilament Printing Mesh/

Screen Printing Mesh/100% Polyester Mesh/10T-165T Screen Printing Mesh/Monofilament Polyester Printing Mesh/Polyester Screen Printing Mesh

Specifications:
1.Weave:Plain

2.Mesh count:18-420mesh/inch(10-165T)

3. Thread Diameter:31-350um

4. Used: Printing

5. Color: Yellow, white, orange

6.Width:115cm,127cm,145cm,158cm,165cm,260cm,320cm .Max 365cm
7.Mesh rolls  with pp bags,2-8rolls per carton,with waterproof bags outside.(customized)

 Features & advantages:
1. Faster turnaround time from the screen room to the pressroom
2. Good diathermancy
3. High air permeability
4. Acid resistance and Alkali resistance
5. Long working life
6. Hard wear
7. Three factories for manufacturing
8. Imported weaving machines from Switzerland and Italy

Need For Quotation:

1.Mesh Count :

2.Thread Diameter :

3.Width :

4.Quantity :

Applications:

Polyester was introduced to the screen printing market over 40 years ago and quickly replaced traditional silk as the fabric of choice among screen printers all over the world. It is a material that is uniquely suitable for screen printing of its tensile strength, elastic memory and resistance to chemicals, abrasion heat and moisture. Polyester screen is a kind of synthetic fabric constructed similar to silk, yet with better uniformity. Compared to silk, polyester screen cloth offers extreme durability, yet has a lower price.

ShangShai  Monofilament Polyester Printing Screen is woven from yarn that is extruded from heated polyester into a single strand. The extruded thread is the spun to a precise diameter. Conventional monofilament polyester screen fabric will elongate under tension: the higher the tension level, the more the thread can stretch. At excessive tension levels, the thread reaches its "plastic deformation" point, and the screen will no longer hold tension.

Our Services

The sample is free for less then 1*1 meter.

For any quality problem, please tell us as soon as possible,and we will try or best to help you.

Your suggestion is the key to success.
