DDR2 SO-DIMM 800MHz 2GB

Payment Terms:	T/T

Inquiry Now Start Safebuy Order

ECVV Safebuy Services

According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
Safebuy Service Guarantee

Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.

Quick Details

Model Number: CIR-S2SUSG8002G
Brand Name: CERVOZ

Specifications

The CIR-S2SUSG8002G is 256M words x 64 bits, 2 ranks DDR2 SDRAM Small Outline Dual In-line Memory Module, mounting 16 pieces of 1GB bits DDR2 SDRAM sealed in FBGA(μBGA?) package. Read and write operations are performed at the cross points of the CK and the /CK. This high-speed data transfer is realized by the 4 bits prefetch-pipelined architecture. Data strobe (DQS and /DQS) both for read and write are available for high speed and reliable data bus design. By setting extended mode register, the on-chip Delay Locked Loop(DLL) can be set enable or disable. This module provides high density mounting without utilizing surface mount technology. Decoupling capacitors are mounted beside each FBGA(μBGA) on the module board.

Specifications

*Density: 2GB

*Pin Count: 200pin

*Type: Unbuffered

*Dimensions: 67.6mm x 30.0mm

*ECC: Non-ECC

*Component Config: 128M x 8 bit

*Data Rate: 800 MHz

*CAS Latency: 6

*Voltage: 1.8V

*PCB Layers: 8

*Operating Temp.(TCASE) : 0°C~+85°C

*Module Ranks: Dual Rank
