Henan Tinde Power Co., Ltd.
China Manufacturer with main products: Abc Cable, Electric Wire, Welding Wire, Bare Conductor, Building Wire, Power Cable, Overhead Insulated Cable, Control Cable |
0.6/1kV PVC Sheath Aerial Bundled Cable
| Supply Ability: | 100,000 Kilometer(s) per Year |
|---|---|
| Shipping: | 10days |
| Payment Terms: | L/C, D/A, D/P, T/T |
-
ECVV Safebuy Services
According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
-
Safebuy Service Guarantee
Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Henan in China |
| Packaging Details: | wooden drum or iron drum |
Quick Details
- Conductor Material: Aluminum
- Application: Overhead
- Type: Low Voltage
- Insulation Material: XLPE
- Brand Name: TINDE
- Jacket: PVC
Specifications
0.6/1kV PVC sheath Aerial Bundled Cable.
ABC usually has 3 cores plus neutral, the neutral can either be bare or insulated and the cable can have a
Street light of 25mm2. ABC is available in 600/1000v, 635/11kV or 12,7/22kV. We stock 1 core, 2 core and 3 core ABC cable.
Construction:
1.Stranded aluminium conduct
2.PE or XLPE insulation
3.ACSR, AAAC,Galvanised steel wire Messenger wire
3 power cores consisting of standard aluminium conductors, insulated with XLPE insulation
+ One sheath lighting aluminium conductor with XLPE insulation(optional)
+ One messenger Al-alloy conductor (bare or covered)
the purpose of messenger wire is
A) It acts as load bearing wire.
B) It acts as earth or neutral conductor
Application:
to be used at cotages of 600V phase-to-phase or less and at conductor temperatures not to exceed 75oC for polyethylene insulated conductors or
90oC for crossliked polyethylene(XLPE) insulated conductors.
Standards:
1. SANS 1418
2. B-231 Aluminum Conductors, Concentric-Lay-Stranded.
3. B-232 Aluminum Conductors, Concentric-Lay-Stranded, Coated Steel Reinforced (ACSR).
4. B-399 Concentric-Lay_Stranded 6201-T81 Aluminum Alloy Conductors.
5. B498 Zinc-Coated Steel Core Wire for Aluminum Conductors, Steel Reinforced (ACSR).
6. Duplex Service Drop cable meets or exceeds all applicable requirements of ANSI/ICEA S-76-474
Voltage:
Rated voltage U0 / U = 0.6 /1 kV
VAC test voltage 5 kV
