CNC Gantry Guideway Grinding Machine9(MK2880)

Payment Terms:	L/C, T/T

Inquiry Now

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Shandong in China

Quick Details

After-sales Service Provided: Engineers available to service machinery overseas
Model Number: MK2880
Brand Name: ZZMM
Max. Grinding Length: 8000
Max. Grinding Diameter: 2800
CNC or Not: CNC
Type: Universal
Condition: New

Specifications

Features:
1.Composed of PLC,hydraulic transmission system,servo motor-reducer-ball screw drive system,box shape frame,etc.
2.Horizontal grinding head is mainly for grinding level plane(Grinding incline 90°of V type guideway is possible),vertical grinding head is for side plane(Electrical angle adjustment&hydraulic locking,grinding incline of V type guideway&swallow-tail slot at any angle is possible).
3.Gantry structure and close,strong&box structure composed of double column,beam&bed.Rectangular staged guideway with good mechanical property&high rigidity.
4.State-patented spindle for horizontal grinding head and roller bearings for vertical grinding head.
5.Stepless&stable table motion with low noise,independent hydraulic station with cooling unit.Long-range-control&stepless table moving speed with inching&auto function.
6.It is with auto lubrication and it stops&alarms automatically if oil not enough.

Specifications	MK1630	MK1640	MK2040	MK2060	MK2080	MK2440	MK2460	MK2480	MK2860	MK2880
Max.Grinding width/length mm	1600/3000	1600/4000	2000/4000	2000/6000	2000/8000	2400/4000	2400/6000	2400/8000	2800/6000	2800/8000
Max.grinding height(H./V.)mm	800/750	800/750	1200/1050	1200/1050	1200/1050	1200/1050	1200/1050	1200/1050	1500/1200	1500/1200
Max.work-piece height mm	800	800	1200	1200	1200	1200	1200	1200	1500	1500
Max.work-piece weight kg	5000	6000	8000	10000	12000	10000	14000	18000	25000	30000
Distance between columns mm	1700	1700	2100	2100	2100	2500	2500	2500	3000	3000
Table width/length mm	1250/3000	1250/4000	1600/4000	1600/6000	1600/8000	2000/4000	2000/6000	2000/8000	2500/6000	2500/8000
T-slot quantity/width	7/28 mm	7/28 mm	9/28 mm	9/28 mm	9/28 mm	9/28mm	9/28mm	9/28mm	11/28mm	11/28mm
Max.table travel mm	3200	4200	4200	6200	8200	4200	6200	8200	6200	8200
Table moving speed m/min	5-18	5-18	5-18	5-18	5-18	5-18	5-18	5-18	5-18	5-18
Spindle speed(H./V.)rpm	1300/1450	1300/1450	1300/1450	1300/1450	1300/1450	1300/1450	1300/1450	1300/1450	868/970	868/970
Sand-wheel size(H/V,O./W./I.)mm	φ500/75/φ203	φ500/75/φ203	φ500/75/φ203	φ500/75/φ203	φ500/75/φ203	Φ500/75/203	Φ500/75/203	Φ500/75/203	Φ600/100/203	Φ600/100/203
Sand-wheel size(H/V,O./W./I.)mm	φ405/62/φ127	φ405/62/φ127	φ405/62/φ127	φ405/62/φ127	φ405/62/φ127	Φ405/62/φ127	Φ405/62/φ127	Φ405/62/φ127	Φ500/75/φ203	Φ500/75/φ203
Main Motor power(H./V.)Kw	11/7.5	11/7.5	11/7.5	11/7.5	11/7.5	11/7.5	11/7.5	11/7.5	22/11	22/11
Dimensions(L./W./H.)mm	12000/6000/6000	16000/6000/6000	16000/6500/6500	21000/6500/6500	25000/6500/6500	16000/7200/6500	21000/7200/6500	25000/7200/6500	21000/9000/6600	25000/9000/6600
