Mono and Multi-filament Woven Fabric for Paper Sheet Forming and Conveying

FOB Price:	1.00 - 8.00 USD/Square Meter
Supply Ability:	200,000 Square Meter/Square Meters per Year
Shipping:	4 Weeks
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram

In Stock

Inquiry Now

Related products from verified members

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Guangdong in China
Packaging Details:	Woodenbox, Cardboard Tube, Protective Foam

Quick Details

Model Number: 7 Shaft
Brand Name: Keylife
Application: Wet End in Paper Machine
Paper Grade: Brown Grade Paper
Size: Max.100m long and 12m wide
Looms: Jurgens and Texo
Seaming Machine: WIS

Specifications

The forming section consists of a long moving belt of fine mesh screen supported by rolls or foils. For many decades, this screen belt was made of bronze and called the " wire." Today it is made of synthetic polymer — primarily polyester monofilament — and is called the forming fabric. Newer machines (gap formers) trap the slurry out of the slice between two forming fabrics. As the forming fabric moves along the forming section, water drainage is assisted by foils. The fiber then passes over the suction boxes to pull more water from the furnish. Still more water is removed at the couch roll just before the sheet leaves the forming section. At this point, the sheet consistency is about 20%.

Dedicated research has produced synthetic forming fabrics that yield improved drainage, higher production and longer life at a lower cost per ton of paper produced.

Keylife's forming fabrics are available in a wide variety of meshes, depending on the type of paper produced. Coarse mesh fabrics are used to manufacture heavy paper grades such as those used in the production of corrugated boxes. Very fine mesh fabrics are required for lightweight paper, such as writing paper, book paper and magazine paper. The average life span of a forming fabric, depending on the type of paper, is approximately three months.

10 shaft 1.5 layer fabrics for long life potential and improved stability. Available in standard polyester or polyamide, which can promote greater life potential and reduced energy consumption. 5 shaft single layer designs are also available for tissue application.

Material: Polyester monofilament (PET 100%)

Polyester forming fabric can be divided into 4-shed, 5-shed, 7-shed, 8-shed, 16-shed and 24-shed based on the weaving structures. And it can also be divided into single layer, double layer, two and a half layer, three layer and SSB triple layer forming fabric based on the categories.
