V-Type High Efficient Mixing Machine

Supply Ability:	999 Unit/Units per Year
Shipping:	30 Days
Payment Terms:	L/C, D/P, T/T, Western Union

Inquiry Now

Related products from verified members

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Shanghai in China
Packaging Details:	EXPORT STANDARD

Quick Details

After-sales Service Provided: Engineers available to service machinery overseas
Warranty: 1 Year
Dimension(L*W*H): 3300*1000*1750mm
Power(W): 4kw
Voltage: 380V
Max. Loading Capacity: 600L
Model Number: V-1.5
Brand Name: STH
Additional Capabilities: Mixing Machine
Condition: New

Specifications

The cylinders have elegant appearance. The charging of materials can be made either by manual operation or through vacuum suction. For discharging rotating valves and rapid swivel heads are adopted. This mixer is applicable for mixing powder or granular materials in pharmaceutical and other industries. Is consists of two V-type cylinders of different altitudes, and throng mechanical transmission the materials in and again, thereby achieving the goal of uniform mixing

Model	V-0.1	V-0.2	V-0.3	V-0.5	V-1.0	V-1.5	V-2.0	V-2.5	V-3.0
Total Capacity (M³)	0.1	0.2	0.3	0.5	1.0	1.5	2.0	2.5	3.0
Loading factor	0.4	0.4	0.4	0.4	0.4	0.4	0.4	0.4	0.4
Max loading capacity (L)	40	80	120	200	400	600	800	1000	1200
Overall Size (mm)	19006001190	22707001440	23208001470	25209001510	304010001765	330010001750	370012002000	395015502200	410015002140
Rotating speed (r/min)	15	15	15	15	12	10	10	8	6
Motor power (kw)	1.1	1.5	1.5	1.5	3	4	5.5	7.5	7.5
Total Weight (kg)	180	250	350	550	1000	1100	1500	1700	1800
