Qingdao Hnyn Microelectronic Co., Ltd.
China Manufacturer with main products: Directional Sensor, MWD Sensor, Quartz Accelerometer, Linear Regulator, High Temperature Memory, Thick Film Circuit Module, Xrmi Honeywell,... |
High Temperature Flash Memory
| Supply Ability: | 1,000 Piece/Pieces per Year |
|---|---|
| Shipping: | 60 DAYS |
| Payment Terms: | L/C, T/T |
-
ECVV Safebuy Services
According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
-
Safebuy Service Guarantee
Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Shandong in China |
| Packaging Details: | Special package |
Quick Details
- Operating Temperature: 45~175
- Dissipation Power: 5~100mW
- Supply Voltage: 2.7V~3.6V
- Application: Petroleum measurements instrument
- Type: Logic ICs
- Model Number: LHNF4GA
- Brand Name: HNYN
Specifications
1. Introduction
LHNF1GA is a high temperature and reliable HAND type and commonly used memory, has fast read and write, high reliability and good performance characteristics under high and low temperature and can operate continuously under severe environment of -45℃~175℃.
|
Product model |
Voltage scope |
Structure |
Encapsulation method |
|
LHNF1GA |
2.7V~3.6V |
1G*8 bit |
DIP16 |
2. Characteristics
Working temperature scope: -45℃~+175℃
The maximum working current: 90mA; standby current: ＜2mA
Power supply voltage Vcc (V): 2.7V~3.6V
Input high level (V): 0.8Vcc~Vcc+0.3
Input low level (V): -0.3~0.2Vcc
Output high level (V):2.4~Vcc
Output low level(V): -0.3~0.4
Encapsulation: 16 PIN DIP lead-free encapsulation (45mm*28mm*5mm)
