Home >Products Catalog > Hydraulic scissor car parking lift > Car Parking Lift Hydraulic Vehicle Parking 2 Level Two Layer for Villa

Car Parking Lift Hydraulic Vehicle Parking 2 Level Two Layer for Villa

FOB Price:	5,000.00 - 9,800.00 USD/Set
Supply Ability:	6,000 Unit(s) per Year
Shipping:	FOB Qingdao
Payment Terms:	L/C, T/T

In Stock

Inquiry Now

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Shandong in China
Packaging Details:	Iron case or plywood case package

Quick Details

Warranty: 24Months
Model Number: SJG2.6-2.8
Brand Name: SDLIFT
Overall Width(mm): 2500mm
Lifting Height(mm): 2800mm
Lifting Capacity: 2600kgs
Type: Double Cylinder Hydraulic Lift
Design: Scissor
power: 5.0kw
install: underground
Type of Products: hydraulic scissor car lift
Color: optional
Motor: customer required brand or Chinese famous brand
Safety device: explosion proof lock valve, emergency
Package: Iron case or plywood case package

Specifications

Car parking system hydraulic vehicle parking 2 level two layer for villa:

Product description:

MODEL	LOAD CAPACITY	PLATFORM SIZE	LIFT HEIGHT	PIT DEPTH	POWER
SJG2.5-3	2.5T	5.2m x 2.6m	3m	750mm	220V, 240V, 380V or 400V
SJG2-6.5	2T	5.2m x 2.8m	6.5m	800mm	220V, 240V, 380V or 400V
SJG2.5-3.5	2.5T	5.2m x 2.6m	3.5m	800mm	220V, 240V, 380V or 400V
SJG2.5-5	2.5T	5.6m x 3m	5m	800mm	220V, 240V, 380V or 400V
SJG3-2.5	3T	5m x 2.3m	2.5m	750mm	220V, 240V, 380V or 400V
SJG3-3	3T	5.2m x 2.6m	3m	800mm	220V, 240V, 380V or 400V
SJG3-3.5	3T	5.6m x 2.7m	3.5m	800mm	220V, 240V, 380V or 400V
SJG5-10	5T	4.5m x 2.5m	10m	1150mm	220V, 240V, 380V or 400V
SJG8-2.5	8T	6.5m x 4.5m	2.5m	850mm	220V, 240V, 380V or 400V
SJG12-3	12T	5.5m x 2.8m	3m	950mm	220V, 240V, 380V or 400V
SJG15-4.5	15T	8m x 2.2m	4.5m	1150mm	220V, 240V, 380V or 400V
SJG20-5	20T	6m x 3m	5m	1200mm	220V, 240V, 380V or 400V
the 2 level car lift elevator for villa can be customized as your detailed size.

Configuration:

1) Platform Material: rectangular tube + checkered iron
2) Scissor material: high strength Manganese Steel.
3) Hydraulic system: 220v, 380v, or other.
4) High Precision Hydraulic Cylinder.
5) Piston Rod: hard chromium plating surface.
6) High-pressure oil pump
7) Hydraulic oil: summer 45#, winter 32#
8) Controller: 1 control box below, 1 control panel above platform
Car parking lift hydraulic vehicle parking 2 level two layer for villa

Safety:

1) Explosion-proof lock valve to avoid a sudden drop if emergency occurs.

2) the safety rails to guarantee safety of the goods above lift platform.

3) Equipped 4 guide rails, to ensure the 2 level car lift elevator for villa runs more smoothly and steadily.

4) the limit switch system helps 2 level car lift elevator for villa to stop at accurate position.

5) Electricity leakage protection device is equipped on, all electric components are CE certified.

6) All the 2 level car lift elevator for villa are passed 1.2 times loading test before.
Our services:

1) We can design the customerized 2 level car lift elevator for villa as per your requirement.

2) the most suitable 2 level car lift elevator for villa will be recommended to you once we got your requirement.

3) Shipment can be arranged from our port to your destination port.

4) Operation video can be sent to you if needed.

5) the guarantee is 12 months. Two set spare parts is free for you together with product.

6) 24 Hours technical support, email, telephone or Skype.

Company information:
We are a specialized manufacture in the production of all kinds of lift tables. Includes stationary scissor lift table, hydraulic scissor car lift, double car park lift, guide rail cargo lift, wheelchair lift, trailing scissor lift, trailing aluminum alloy mast lift, trailing articulated boom lift, self-propelled scissor lift table, and mobile and fixed dock rampWe are a specialized manufacture in the production of all kinds of lift tables. Includes stationary scissor lift table, hydraulic scissor car lift, double car park lift, guide rail cargo lift, wheelchair lift, trailing scissor lift, trailing aluminum alloy mast lift, trailing articulated boom lift, self-propelled scissor lift table, and mobile and fixed dock ramp.
