Zibo Shengshuo Chemical Equipment Co., Ltd.
China Manufacturer with main products: Glass Lined Reactor, Electical-Heating Glass Lined Reactor, Glass Lined Distiller, Stainless Steel Reactor, Glass Lined Storage Tank, Glass... |
Home
>Products Catalog > Storage tank > Pressure Vessel New Condition and ISO9001:2008 Certification Boiler Water Storage Tank
Pressure Vessel New Condition and ISO9001:2008 Certification Boiler Water Storage Tank
| FOB Price: | 2,500.00 - 160,000.00 USD/Set |
|---|---|
| Supply Ability: | 3,000 Set/Sets per Year |
| Shipping: | Wthin 30 days |
| Payment Terms: | T/T |
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Shandong in China |
| Packaging Details: | Nude packing with wooden pallet or steel pallet,also packed as customer request |
Quick Details
- After-sales Service Provided: Engineers available to service machinery overseas
- Warranty: 1 year
- Certification: ISO 9001
- Weight: 236 kgs--16800 kgs
- Dimension(L*W*H): Dia:600mm--3000mm; Height:1615mm--8565mm
- Brand Name: Shengshuo
- Capacity: 300-50000L
- Condition: New
- Design temperature: 200 C
- Operation temperature: 0-180 C
- Type of tank: Vertical type and Horizontal type
- Application: Various chemical medias,pharmaceuticals,dyeings,pesticides etc
Specifications
Technical parameter
(1)Nominal Volume:
F Type vertical glass lined storage tank:3000L-50000L
F Type horizontal glass lined storage tank:3000L-50000L
(2)Design temperature:200°C.
(3)Glass coating thickness:0.8mm-2mm
(4)resistant to sharp temprature variation:cool shocking110 °C;hot shocking 120°C
Product feature
(1).Lining burning adopts automatic electrical heating furnace temperature control,
firing glass face clean, quality stability, not easy to crack , not have pollution, not easy to out of shape; Greatly improve the quality of the product and reduce the cost.
All the products with high quality,safety and durability.
(2) Resistant to corrosion effectively.
Other related products:
1.Main Products
|
1.Glass lined reactor |
K-type (50L----12500L) |
|
F-type (1000L----30000L) |
|
|
2.Electrical-heating Glass lined reactor |
K-type(50L----3000L) |
|
3.Stainless steel reactor |
50L----10000L |
|
4.Glass lined storage tank |
Horizontal type(3000L----50000L) |
|
Vertical type(3000L----50000L) |
|
|
5.Glass lined distiller |
K-type(300L----3000L) |
|
F-type(3000L----10000L) |
|
|
Stirrer |
|
Tower section |
|
|
Electric motor |
|
|
Gear reducer |
2.Property of products
Anticorrosion
Acid and alkali resistant
Shockproof
Pressure proof
Inadhesion
3.Technical Characteristics for glass lined products
(1)Allowable pressure (unit:Mpa)
|
Sealing form |
Stuffing seal |
Mechanical seal |
|
|
Pressure parts |
In-tank |
≤0.1 |
(0.1----1.0) |
|
Jacket |
≤0.6 |
||
(2)Allowable temperature
0----200 centigrade for stirrer;
0----150 centigrade for tank.
(3)Thickness of glass layer:(mm)
0.8----2.0mm for the kettle;
0.6----2.3mm for accessories.
(4)Standard thickness of steel plate:(mm)
|
Capacity |
Kettle |
Jacket |
|
50----500L |
8 |
6 |
|
1000L |
10 |
6 |
|
1500L----2000L |
12 |
8 |
|
3000L |
14 |
10 |
|
5000----6300L |
16 |
10 |
|
8000L |
18 |
12 |
|
10000L and above |
20 |
12 |
(5)Accessories:
for reactor: agitator,electromotor,reducer,mechanical seal;
for distiller: tower section.
