Home  >Products Catalog > Embossing machines > Auto sheet to sheet embossing machine Model YW-E

Auto sheet to sheet embossing machine Model YW-E SafeBuy Supplier Member

Shipping: 30% advance payment be paid by TT, balance paymen shall be paid before shipment
Payment Terms: L/C, T/T
Export Markets: North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin: Zhejiang in China
Packaging Details: Standard export package

Quick Details

  • Type: Embossing Machine
  • Certification: CE
  • Weight: depends on machine size
  • Dimension(L*W*H): depends on machine size
  • Voltage: 380V/50HZ/3 PHASE (the voltage can change with surcharge)
  • Driven Type: Hydraulic
  • Packaging Material: Metal,PLYWOOD
  • Condition: New
  • sheet to sheet: manual paper feeding
  • manual paper collection: mechanical button

Specifications

Product description :
The automatic paper embossing machine with the functions like automatic feeding & auto picker collecting paper was developed at the basis of the original embossing machine with manual feeding and collecting, Full automatic control in processing. Adopted frequency governor, automatic hydraulic system and pneumatic blade, it is characterized by controllable speed, double-sheet control, automatic counting, etc. Its average can range form 3000~5000pc/h. It is applied to embossing the sheet surfaces of batches like packing products, playing cards, gift cards, golden and silver card paper, etc.

Optional collector:

-Auto vibrating collector

-Manual collecting table

Main technical parameter :

Model

YW-720E

YW-920E

Max embossing speed

80 m/min

80 m/min

Max embossing width

680mm

880mm

Paper range

>160 g/m2

>160 g/m2

Operation pressure

2-10 Mpa

2-10 Mpa

Main motor pressure

14 kw

15 kw

Vacuum pressure

0.06 Mpa

0.06 Mpa

Air source pressure

1.8-1.0 Mpa

1.8-1.0 Mpa

Overall dimension(LxWxH)

4800x1500x1800 mm

4800x1700x1800 mm

Machine weight

2800 kgs

3500 kgs

Model

YW-1150E

YW-1300E

Max embossing speed

80m/min

80 m/min

Max embossing width

1000mm

1180 mm

Paper range

>160 g/m2

>160 g/m2

Operation pressure

2-10 Mpa

2-10 Mpa

Main motor pressure

16 kw

18 kw

Vacuum pressure

0.06 Mpa

0.06 Mpa

Air source pressure

1.8-1.0 Mpa

1.8-1.0 Mpa

Overall dimension(LxWxH)

4800x1800x1800 mm

    4800x2000x1800 mm

Machine weight

4200kgs

5000kgs
