CCS certificate marine pneumatic rubber fenders

FOB Price:	500.00 - 6,000.00 USD/Piece
Supply Ability:	1,000 Piece/Pieces per Month
Shipping:	by sea shipping
Payment Terms:	T/T, Western Union

In Stock

Inquiry Now

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Shanghai in China
Packaging Details:	Standard type

Quick Details

Part: pneumatic rubber fenders
Model Number: CCME
Brand Name: CCME
R (KN): 2019KN
material: natural rubber+durable dipped tyre
size: optional

Specifications

CCS certificate marine pneumatic rubber fenders

Ease of handling and good buoyancy
Low surface pressure with low reaction and High Energy Absorption Rate

These fenders offer excellent energy absorption characteristic and do have a linear load deflection characteristic. They are very easy to install, remove and

Constructure

1)Outer rubber layer

Rubber layer that covers the outside of the fender to protect the cord layers and the inner liner rubber from abrasion and other external forces.

2)Inner rubber layer

liner of a rubber membrane that seals the pressurized air inside the fender.(In general,we will make some inner rubber container in advance and inflate them.few days later,we will test the pressure again.The one which it's pressure did not change is good one.We will put it into store and when clients order we can use it directly.This can ensure every fender we send to client is airtight one)

3. Flange opening

which is mounted on the fender to which an air valve can be adapted.(our flange are all Embedded welding, very stable)

4. Initial internal pressure

Air pressure at which an uncompressed fender operates.

yokohama pneumatic fender

2.There are two types Pneumatic rubber marine fender :

1)Sling-type fender:fender which is designed to be used without a protection net.

Size	Initial Internal Pressure 0.05MPa		Weight ±10%	Initial Internal Pressure 0.08MPa		Weight ±10%
D*L(mm)	R(KN)	GEA(KJ)	Kg	R(KN)	GEA(KJ)	Kg
500*1000	64	6	25	83	8	25
600*1000	74	8	32	96	11	32
700*1500	137	17	50	178	24	50
1000*1500	182	32	80	235	44	80
1000*2000	257	45	100	335	63	125
1200*2000	297	63	120	386	86	165
1350*2500	427	102	165	554	140	226
1500*3000	597	153	315	751	211	370
1700*3000	639	191	405	830	263	436
2000*3500	875	308	590	1138	424	632
2500*4000	1381	663	1050	1815	925	1110
2500*5500	2019	943	1333	2653	1317	1410
3000*5000	2104	1210	1880	2709	1571	2155
3000*6000	2583	1485	2160	3292	1888	2470
3300*4500	1884	1175	2020	2476	1640	2300
3300*6500	3015	1814	2700	3961	2532	3080
