Blade honing machine Model DMSQ-D
| Shipping: | 30% advance payment be paid by TT, balance paymen shall be paid before shipment |
|---|---|
| Payment Terms: | L/C, T/T |
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Zhejiang in China |
| Packaging Details: | Standard export package |
Quick Details
- Warranty: one year for machine
- Certification: CE
- Power(W): depends on machine size
- Dimension(L*W*H): depends on machine size
- Weight: depends on machine size
- Voltage: 380V/50HZ/3 PHASE (the voltage can change with surcharge)
- Condition: New
Specifications
Drive mechanism
The main transmission is rack and pinion transmission
Machine structure
01. Cantilever-type body: lathe bed casts with mezzo forte cast iron
02. Wide guide rail: good stability stable, using high-frequency quenching
treatment, high strength and good abrasion resistance
Worktable
01. Foundry of cast iron
02. Mechanical loading knife
Major technique parameter:
Polishing form
------------------------------------------------------ Automatic Reciprocating
Honing length most greatly ----------------------------1700mm or more
Tool rest operating angle -----------------------------------------0°～±90
Polishing Wheels Speed------------------------------------------1500 rpm
Polishing Wheels--------------------------------------------------- Wool wheel
Polishing Wheels Specifications--------------------------------18mm
Reciprocating speed ----------------------------------------------8m/min
Polishing motor -----------------------------------------------------YS7124: 0.55KW
Reciprocating motor -----------------------------------------------YS7124 : 0.55KW
Overall dimensions (L * W * H)---------------------------------- 3420*1050*1500
Machine Weight -----------------------------------------------------1800kg
Power of water pump motor-------------------------------------0.125KW
|
No |
Model |
Max. grinding length( mm) |
Outlook size( mm) |
Machine net weight( Kg) |
|
1 |
1700D |
1700 |
2945x900x1330 |
1600 |
|
2 |
2200D |
2200 |
3545x900x1330 |
1900 |
|
3 |
2600D |
2600 |
3945x900x1330 |
2300 |
|
4 |
3000D |
3000 |
4345x900x1330 |
2700 |
|
5 |
3200D |
3200 |
4545x900x1330 |
2900 |
