Surface grinding machine M1022

Shipping:	3 working days after we receive the payment
Payment Terms:	T/T

Inquiry Now

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Jiangsu in China
Packaging Details:	plywood box

Quick Details

Model				M1022
Working table	Table Size (L× W)		mm	540×250
	Max movement of working table(L× W)		mm	560×260
	T -Slot number×width		mm	1×14
Grinding head	Max distance from spindle center to table surface		mm	420
	Wheel Size(Outer diameter×width×Inner diameter)		mm	φ200×20×Φ31.75
	Wheel speed	50HZ	r/min	2850
		60HZ		3360
Feed amount	Vertical feed on handwheel	Per revolution	mm	4.0
		Per graduation	mm	0.02
	Cross feed on handwheel	Per revolution	mm	1.25
		Per graduation	mm	0.01
Motor power	Spindle motor		kw	1.5
	Coolant pump motor		w	40
Working precision	The parallelism of working surface to base level		mm	300:0.005
	Surface roughness		μm	Ra0.32
Weight	Net		kg	850
	Gross		kg	950
Overall dimension(L×W×H)			mm	1680x1220x1720
Package dimension(L×W×H)			mm	1200x1400x1940
