Glass Reinforced Plastic Tank Machine

FOB Price:	10,000.00 - 50,000.00 USD/Set
Supply Ability:	100 Set/Sets per Month
Shipping:	by sea
Payment Terms:	L/C, T/T

In Stock

Inquiry Now

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Hebei in China
Packaging Details:	Nude packing for loading container

Quick Details

Dimensions: as per requested
Technique: winding process making barrel with concace convex wheel shaped head
Surface Treatment: winding process
Application: making FRP products
Model Number: C-03011
Brand Name: WJ

Specifications

FRP storage tank, fermentation tank, large FRP tower, large FRP chimney, FRP desulphurization equipment,large corrosion-resistant tank and etc.
This production line is characterized by the high precision of winding line, high productivity, low energy-consumption, easy installation, adjustment and maintenance. It adopts the industrial computer control, so the usage and operation are very convenient.
Specifications

GRP pipe winding machine

FRP vessels winding machine

FRP membrane housing winding machine

Manual,semi-automatic,automatic

GRP tank machine and FRP vessels winding machine is mainly used to produce and manufacture the FRP vertical winding molded vessels as well as the related winding molded products, such as FRP storage tank, fermentation tank, large FRP tower, large FRP chimney, FRP desulphurization equipment,large corrosion-resistant tank and etc. This production line is characterized by the high precision of winding line, high productivity, low energy-consumption, easy installation, adjustment and maintenance. It adopts the industrial computer control, so the usage and operation are very convenient.

Vertical Winding Machine of FRP Tank
Equipment Name Item Name	FWLS-10000	FWLS-15000
Pipe diameter,IDmm	Φ3000-Φ10000	Φ4000-Φ15000
Product height,mm	≤8000	≤9000
Winding angle,	6590	6590
Max weight of product,kg	32000	45000
Rotating speed of main shaft ,r/min	≤18	≤12
Transmission method	Pinion and rack	Pinion and rack
Control method	manualsemi automaticautomatic	manualsemi automaticautomatic
Coordinate speed of vehicle,m/min	45	45
Precision of lining up yarn ,mm	±1	±1
Repositioning accuracy ,mm	0.2	0.2
Max speed of pulling yarn ,m/min	90	90
Max width of yarn tape ,mm	200	200
Winding type	Reciprocating cross, hoop direction	Reciprocating cross, hoop direction
Winding roving capacity,each	80	80
Resin type	Unsaturated polyester, vinyl ester, etc.	Unsaturated polyester, vinyl ester
Yarn framea kind of inner pulling yarn	Tension adjustable yarn frame of mechanical type	Tension adjustable yarn frame of mechanical type
Impregnation groove,stainless steel	Roller impregnation or immersion impregnation	Roller impregnation or immersion impregnation
Production capacity ,kg/h	2000	2000
Total installed capacity , kw	15	18
Areas covered by production linelength × width × heightm	10×12×10	15×18×11

Each parts of GRP coupling socket machinery:

Feeding system--formation system--driving system--groove making system--surface planning system etc.

Coupling socket technology data

Model:	TZ-2600
Driving power(KW)	5.5
Feeding system powerKW	11
Specifications (MM)	300-2600

Packaging & Shipping

Packaging

Standard sea-worthy package mainly with wooden pallet and film coverage for the main machine body; wooden cases for electrical parts & consumable parts. In 3 40' containers.
