Shanghai Believe Industry Co., Ltd.
China Manufacturer with main products: Roll Forming Machine, Cold Rolling Mill, Sandwich Panel Forming Machine, Slitting Line and Cut to Length Line, Radiator Production Line,... |
Portable Downpipe Roll Forming Machine
| FOB Price: | 15,000.00 - 18,000.00 USD/Set |
|---|---|
| Supply Ability: | 60 Set/Sets per Quarter |
| Shipping: | Shanghai Port |
| Payment Terms: | L/C, T/T |
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Jiangsu in China |
| Packaging Details: | Nude Packaging |
Quick Details
- After-sales Service Provided: Engineers available to service machinery overseas
- Warranty: 18 months
- Voltage: 380V, 50Hz, 3Phase
- Model Number: Customized
- Brand Name: Believe Industry
- Production Capacity: 60 sets / quarter
- Use: Roof
- Tile Type: Steel
- Type: rain downpipe machine
- Condition: New
Specifications
Description:
This portable downpipe roll forming machine is used in manufacturing down pipes and its specific dimension is made at customers' requirements. The main components of this device are decoiler, roll former, cutting device, control cabinet, and pipe bending machine, etc.
| Technical Parameters | |
|---|---|
| Raw Material | Steel, Aluminum, Copper |
| Material Thickness | 0.3-0.8mm |
| Material Width | Depend on specific profile |
| Diameter of Shaft | 50mm |
| Material of Shaft | 45# steel |
| Material of Rolls |
45# steel Chromed with thickness 0.05mm |
| Main Power | 2.2KW |
| Forming Speed | 6-8m/min |
| Forming Station | 11 stations |
| Cutting Type | Hand Operate |
| Cutting Blade |
Cr12 Mov |
