Kraft Machinery Co., Ltd.
China Manufacturer with main products: Manual Lathe, CNC Lathe, Boring Mill Machine, Machine Center, Universal Milling, Radial Drilling, Oil Country Lathe, Gantry Milling |
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|
Specifications
| Model | VMC600L | VMC800L | VMC1000L | VMC1200L |
| Travel of X/Y/Z axis(mm) | 600/320/450 | 700/400/500 | 1000/560/560 | 1200/660/660 |
| Distance from spindle nose to the table surface(mm) | 100-550 | 120-620 | 140-700 | 140-800 |
| Distance from spindle center to column's guide way surface | 360 | 460 | 610 | 710 |
| Rapid traverse rate X/Y/Z axis(m/min) | 18/18/18 | 24/24/18 | 20/20/18 | 20/20/18 |
| Table size ( L x W )(mm) | 800X320 | 800X400 | 1100x550 | 1300x600 |
| Max. loading capacity(kg) | 300 | 500 | 750 | 950 |
| T slot(mm) | 3/14/100 | 5/18/125 | 5/18/100 | 5/18/125 |
| Spindle Speed(rpm) | 8000 | 8000 | 8000 | 8000 |
| Spindle taper | BT40 | BT40 | BT40 | BT40 |
| Spindle motor power(kw) | 3.7/5.5 | 5.5/7.5 | 7.5/11 | 11.0/15 |
| Tool magazine type | Drum/Disc | Drum/Disc | Drum/Disc | Drum/Disc |
| Tool magazine capacity | 16/20/24T | 16/20/24T | 16/20/24T | 16/20/24T |
| Tool changing time(s) | 2.5/5 | 2.5/5 | 2.5/5 | 2.5/5 |
| Max. tool diameter(mm) | 80/150,80/130 | 80/150,80/130 | 80/150,80/130 | 80/150,80/130 |
| Max. tool length(mm) | 300 | 300 | 300 | 300 |
| Machine weight(kg) | 2500 | 3200 | 6000 | 7500 |
Service Guarantee
-
Free Service Charge
ECVV doesn't charge any service fee to Buyers for buying this product.
-
ECVV Supply
ECVV is responsible for supply, and provides product quality inspection, fund supervision and supply chain services.
-
Product Quality Commitment
ECVV China Sourcing Agent will assess the reputation and supply ability of the factory and conduct field trips to select the high-quality Chinese factories for buyers.
-
Deposit Service Commitments
In order to improve the quality of service, ECVV will charge for a 100CNY deposit for the agent purchasing order, and the deposit will be part of subsequent purchasing costs.
After paying a deposit, if the purchasing order is not completed because of unsatisfied ECVV services, ECVV will refund your deposit.
linear way and box way from this supplier
More products from other suppliers
FOB Price: 1,500.00-1,600.00 USD/Piece
Min Order: 1 Piece
