2500 degree ultra high temperature IF carbonization furnace with infrared potics temp- measurement

FOB Price:	30,769.00 - 76,923.00 USD/Set
Supply Ability:	60 Set/Sets per Month
Shipping:	60 days for estimated time of arrival, shenzhen port
Payment Terms:	T/T

In Stock

Inquiry Now Start Order

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Hunan in China
Packaging Details:	export standard packing by professional packing staff or packing as per the customer's request

Quick Details

After-sales Service Provided: Engineers available to service machinery overseas
Warranty: 1 year
Certification: ISO and CE certification
Power(W): 160kw
Voltage: 380V for inlet cable voltage
Model Number: NT-CF-160
Brand Name: no brand
Usage: carbonization application
Type: intermediate frequency carbonization furnace
Condition: New
the highest temperature: 2500degree
ultimate vacuum degree: 3.6*10-3Pa
heating power: 160kw
temperature measurement type: infrared potics
IF frequency: 2500Hz

Specifications

Intermediate frequency carbonization furnace

●Application

●Feature
On the basis of the Sweden Sendonvick, the addition of a high performance, intelligent temperature control system and a full range of temperature regulation and protection functions, with advanced man-machine dialogue and fault self diagnosis function. The product quality through this type equipment producing is much better than traditional carbon tube furnace, it is the replacement product of carbon tube furnace; high temperature zone size of 450mm x 1000mm; production of 1.2t, maximum temperature of 2300℃C; working atmosphere of hydrogen gas or vacuum.

The highest working temperature of 2300℃,suitable for most of process necessary, working atmosphere furnace inner:H2,N2; H2 flow rate of 1.5m3/h, N2 flow rate of 2m3/h, temperature measurement: temperature measurement with infrared optics, the range of temperature measurement: 800~2200℃ or 0~2300℃; temperature measurement precision: 0.2~0.75%;

●Uniformity of furnace temperature

Ultimate speed of temperature rise: 100℃/min(empty furnace), temperature uniformity: ≤±10℃; temperature control: PID intelligentialize control and manual control program; temperature control precision: ±1℃

●High degree of automation equipment
Medium frequency induction carbonization furnace is a type of high performance intelligentialize electric furnace suitable well for cemented carbide field (also suitable for other field using)launched by our engineer and technican through absorbing and digesting domestic and foreign most advanced temperature measurement and control technology, intelligentialize, new material technology and furnace body design technology, IF induction carbonization furnace by our company producing is a type of intermittent gas (vacuum) protection furnace, according to the need of the process time for the carbonization furnace, can take single power supply to match for many furnace, proceeding power on to temperature rise and power off to temperature reducing on single furnace for the purpose of achieving continuous working.
●Technical parameter
High temperature area size: ф450mm×1000mm, capacity can reach 150L

Parameter name	unit	KGPS-100	KGPS -160	KGPS -200	KGPS -250
Crucible effective capacity(diameter x height)	mm	Φ200×300	Φ450×900	Φ500×1050	Φ650×1200
IF power	Kw	100	160	200	250
IF power supply frequency	Hz	2500	2500	2500	2500
The highest working temperature	℃	2500	2500	2500	2500
Ultimate vacuum degree	Pa	1.2×10-1	1.2×10-1	1.2×10-1	1.2×10-1
Pressure rise rate	Pa/h	0.5	0.5	0.5	0.5
Temperature difference in constant temperature zone	℃	±10	±10	±10	±10
