Hangzhou Qianhe Precision Machinery Co., Ltd.
China Manufacturer with main products: Magnetic Tensioner, Electronic Tensioner, Magnetic Tensioner with Cylinder, Tooling Accessories, Tungsten Carbide Nozzle, Ruby Ceramic... |
Magnetic Wire Coil Winding Tensioner For Coil Winding Machines
| FOB Price: | 100.00 - 500.00 USD/Set |
|---|---|
| Supply Ability: | 5,000 Set/Sets per Month |
| Shipping: | By Air /By Sea |
| Payment Terms: | T/T, Western Union |
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Zhejiang in China |
| Packaging Details: | Carton with Foam |
Quick Details
- PProduct weight: 0.55kg
- Color: White
- Suit: High and Normal Speed Winding
Specifications
Hangzhou Qianhe Precision Machinery Co.,Ltd
We are specicalized in coil winding mahince tensioners,
Such as Magnetic tensioner,electronic tensioner and servo tensioner
with high quality and the most competitive price in china.
Our wire tensioners can be used on almost any brand of coil winding machine,
and most models can be fitted with a microswitch for detection of broken winding wires
on request .
There is description about Magnetic tensioner as following:
Key advantages of Magnetic wire tensioners:
These magnetic tensioners use a device containing a permanent magnet as a
non-contact method of generating a variable resistance to rotation of the main
wheel of the tensioner, thus maintaining wire tension at the set value for longer
periods than their mechanical counterparts with greatly reduced requirement for
adjustment.
- The arm position provides feedback to the system, adjusting the magnetic resistance device to regulate and maintain constant tension during the winding cycle.
- Wool Felt provide pre-tension and remove dust and other debris from the winding wire.
- Polished ceramic eyelets and guide rollers at each point of contact protect the insulating enamel from mechanical damage.
- The performance of these magnetic wire tensioners is exceptional given the low cost,providing outstanding value for money.
- Captive roller on tension arm is easy to thread, eliminates chance of losing wire.
Specification :
| Products Series | Model | Tension Scope | Applied wire diameter | Tension Rod |
| (g) | (mm) | |||
| MTC Series (vertical type) | QH-MTCSS | 5-130 | 0.025-0.12 | TR-30# |
| QH-MTC300S | 14-400 | 0.06-0.25 | TR-31# | |
| QH-MTCS | 30-800 | 0.08-0.40 | TR-32# |
Tensioner test conditions :
Line speed is 15M/S, instant start, stop the continuous line, stable tension in the positive
and negative 1%g.
Key features of Type MTC300S :
- Tension Scope :30-800g
- diameter 0.08-0.40
- Tension Rod : TR-32#
