USB charger pcb pcb design/pcb clone/pcb manufacture

FOB Price:	0.10 - 10.00 USD/Piece
Supply Ability:	20,000 Square Meter/Square Meters per Month
Shipping:	SHENZHEN
Payment Terms:	T/T, Western Union, MoneyGram, Other, paypal

In Stock

Inquiry Now Start Safebuy Order

ECVV Safebuy Services

According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
Safebuy Service Guarantee

Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.

Related products from verified members

charger

Price:4.00-5.00 USD/Set

Min. Order:100 Sets

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Guangdong in China
Packaging Details:	Vacumn packing for bare board, standand cartons outside for shipping of usb charger pcb

Quick Details

Surface Finishing: HAL(Pb free), plated Ni/Au, Imm silver, Imm Ni/Au/Sn,hard gold,OSP,etc
Min. Line Spacing: 3mil
Min. Line Width: 3mil
Min. Hole Size: 0.15mm
Board Thickness: 0.4-8.0mm
Copper Thickness: 0.5-10oz
Base Material: FR4/ FR1/ FR2/ FR3/ CEM1/ CEM3/ ROGERS/ ARLON/ ISOLA.
Number of Layers: 1-40 layer
Model Number: intech
Brand Name: intech-10
Product name: USB charger pcb pcb design/pcb clone/pcb manufacture
Material: FR4/FR1/ FR2/ FR3/ CEM1/ CEM3/ ROGERS/ ARLON/ ISOLA
Number of layers: 1-40 layers
Board Type: Rigid
Surface treatment: HASL leed free,Imm Au,Imm Ag,Imm Ni/Au/Sn,hard gold,OSP,hard gold etc
Solder mask color: As clients required
Silkscreen color: As clients required
Max board size: 700*1200mm
Application: Electronics Device
Certificates: ISO/UL/TS16949/RoHS/TS16949

Specifications

USB charger pcb pcb design/pcb clone/pcb manufacture

Product Description

Multilayer board capability:

item	technical parameters	specifications
min. line width	1-40layers
min. line space	2mil/2mil	Partial 2mil lines is allowed
min.annular ring width	2mil/2mil	Partial 2mil lines is allowed
min. hole size	vias :3mils ;component holes:7mils	Remained ring width means the distance between the hole edge to the ring outskirt
min. board thickness	0.4mm
max. board thickness	8.0mm
max. board size	700*1200mm
min. board thickness	Single and Double Sided:0.2mm; 4 layers:0.4mm; 6 layers:0.6mm; 8 layers:1.0mm;10 layers:1.2mm
distance between line and board edge	0.2mm
solder mask	White,Black, Blue,Green,Yellow,Red ect
ledgend color	White,Black,Yellow ect
surface finish	HAL(with Pb free),Plated Ni/Au,Immersion Silver ,Imm Ni/Au, Imm Sn, Hard gold, OSP etc.
plating thickness	hard gold :Au(5uin-120uin);imm gold:Au(2uin-4uin);gold finger:Au(5uin-120uin)
copper plating hole	20um-25um
base copper thickness	1/3oz-6oz
finish copper thickness	1-10oz(outerlayers);0.5oz -6oz (innerlayers)
min. insulation layer thickness	2mil
line width /space	max. copper thickness	Line width shouldn't be less than the required value under ensure of space
3mil/3mil;4mil/4mil;4mil/5mil	0.5oz
4mil/6mil/5mil/5mil;6mil/5mil	1oz
5mil/6mil;6mil/6mil	2oz
6mil/8mil;7mil/8mil;8mil/8mil	3oz
8mil/10mil;9mil/10mil;10mil/10mil	5oz
board materials	FR4/FR1/ FR2/ FR3/ CEM1/ CEM3/ ROGERS/ ARLON/ ISOLA
hole size tolerance	+/-0.03mm
hole position tolerance	+/-0.03mm
board outline tolerance	L<=100mm: 0.1mm; 200mm<L<=300mm: 0.3mm; 100mm<L<=200mm:0.2mm;L>300mm: 0.4mm
finished product thickness tolerance	0.2mm<T<0.5mm: +/-0.05mm; 0.5mm=<T<0.8mm: +/-10%; T>=0.8mm: +/-8%
impedance controal	± 10%
bow and twist	≤0.5%
