Quick Details
- After-sales Service Provided: Engineers available to service machinery overseas
- Warranty: 1 year
- Certification: CE
- Usage: Paper Forming Machine
- Automatic Grade: Automatic
- Condition: New
Specifications
The bags opening or valve in one corner through which the sack is filled. The valve is made with an inner flap which functions as a self-closing check valve after filling. It is available with a plain valve or with an extended inner sleeve of paper or film.
Machine Technical Parameters:
ZT9804 TUBER
Printer
| Color of printing | 4 colors available |
| Diameter of print roller | ?144~?314 mm |
| Printing width | 1300 mm(MAX) |
| Running Speed | 130~150 tubes/min |
| Tube length | 670~1035 mm |
| Tube width | 420~600 mm |
| Space between tape steps | 20 mm |
| Tube Cut Length | 670~1035mm |
| Number of ply | 2~4 paper + 1 PP/PE(optional) |
| Paper reel width | 860~1260 mm |
| Paper reel diameter | Max. 1, 300 mm |
| Air consumption | 1,100L/min |
| Main drive motor | 30kw |
| Size of whole set | 34.3m×2.4m×2.7m( L×W×H) |
| Total weight | 30 T |
| Running Speed | 80~130 bags/min |
| Bag length | 520~880mm |
| Bag width | 420~600 mm |
| Bottom width | 90~130mm |
| Bottom open width | 200~380mm |
| Distance between bottom centers | 420~780mm |
| Valve sheet length | 100~250mm |
| Valve sheet width | 120~170mm |
| Main drive motor | 33kw |
| Total weight | 22.7T |
| Size of whole set | 21.3m×2.3.m×1.8m ( L×W×H) |
Our Advantage:
- Specialize in design and manufacture valve paper bag machine for 30 years;
- CE Certified;
- Our tuber machine and bottomer machine have gained over 50 utility model patents;
- Longer service life with NSK bearings,SIEMENS control system and high quality gearings.
- Cost effective compare to W&H,Germany and Newlong,Japan.
