OEM LOGO WDS-620 High Praised 110V/220V automatic bga 3 zone rework station
| FOB Price: | 1.00 - 3,000.00 USD/Piece |
|---|---|
| Supply Ability: | 800 Set(s) per Month |
| Shipping: | 3 days after payment |
| Payment Terms: | T/T, Western Union, MoneyGram, Other, Paypal |
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Guangdong in China |
| Packaging Details: | Wooden box |
Quick Details
- Type: Other
- After-sales Service Provided: Engineers available to service machinery overseas
- Certification: CE ISO
- Usage: bga vga chips repair
- Weight: 60kg
- Dimensions: L650*W630*H850mm
- Rated Duty Cycle: available
- Rated Capacity: available
- Current: Dependable
- Voltage: 110V/220V
- Model Number: WDS-620 automatic bga 3 zone rework station
- Brand Name: WDS automatic bga 3 zone rework station
- Machine type: automatic bga 3 zone rework station
- Advantages: Semi automatic optical alignment
- material: touch screen, PLC, heating plate
- business type: Professional factory
- PCB Size: Max 410*390mm Min 10*10mm
- Heating Ways: hot air + IR
- warranty: 3 years
- packaging: wooden box
- after-sales service provided: Overseas service center available
- usage: repair all kind of bga chips
Specifications
OEM LOGO WDS-620 High Praised 110V/220V automatic bga 3 zone rework station
Our BGA Rework Station/ BGA reballing station are widely used to replace and repair the BGA chip in laptop, mobile phone, xbox360,ps3,etc.
The main user is repairing shops and factory to provide the after-sales service and rework.
How to separate BGA chip from motherboard?
How to replace a new BGA chip?
Repair steps:
1) Separate the BGA chip from mother board –we called desoldering
2) Clean Pad
3) Reballing or replace a new BGA chip directly
4) Alignment/Positioning – Depend on experience ,silk frame ,optical camera
5) replace a new BGA chip - we called Soldering
Product Description
Parameter of WDS-620 automatic bga 3 zone rework station :
|
1 |
automatic soldering desoldering chips |
Yes samsung mobile phone repair machine |
|
2 |
Power supply |
AC 110V/220V±10% 50/60Hz |
|
3 |
Total power |
Max 5300W |
|
4 |
Heater power |
Upper temp.zone 1200W,second temp.zone 1200W,IR temp.zone 2700W |
|
5 |
Electrical material |
Driving motor+PLC smart temp.controller+color touch screen |
|
6 |
Temperature controlling |
(high precision K-sensor)(Closed Loop),independent temp.controller,the precision can reach ±1℃ |
|
7 |
Locating way |
V shape slot,PCB support jigs can adjust,laser light do fast centering and position |
|
8 |
PCB size |
Max 400×390mm Min 10×10 mm |
|
9 |
Applicable chips |
Max 80×80mm Min 1×1 mm |
|
10 |
Overall dimension |
L650×W630×H850mm |
|
11 |
Temperature Interface |
1 pcs |
|
12 |
Weight of machine |
60KG |
|
13 |
Color |
White |
Full Feature of WDS-620 automatic bga 3 zone rework station :
Independent 3 heating zones temperature control system
1.The upper and lower hot air heating,which can heat up at the same time from the top of he component to the bottom of the PCB;bottom IR heating,temperature precision control within ±1℃.8 segment temperature control independently. automatic bga 3 zone rework station
2.Hot air district heating for BGA and PCB at the same time,and large area IR heater preheating up for the bottom of PCB to avoid completely PCB deformation during reworking,the upper or lower temperature zones could be used alone and combine freely the energy of up and lower heating element.
3.Adopted high precision K-type thermocouple close-loop control and PID parameter self-setting system;
4.temperature curves can be displayed with instant curve analysis function and multi-group user data can be saved;temperature can be tested precisely through external measurement interface, curves can be analysed,set and correct on the touch screen at any time. automatic bga 3 zone rework station
Precision optical alignment system
Using high definition and adjustable CCD color optical alignment system,beam split,amplification ,lessening,fine adjustment and auto focus with the function that automaticcolor aberration resolution and brightness adjustment,adjustable image contrast;equipped with 15 " high definition LCD monitor.
Multi-functional and humanized operation system
1.Adopting the HD touch human-machine interface;upper heating head and mounting head designed 2 in 1;providing many kinds of titanium alloy BGA tuyere can be rotated in 360 degree for easy installation and replacement. automatic bga 3 zone rework station
2.X,Y and R angle adopted micrometer fine-tuning,accuracy locating,precision can reach ±0.01mm. zm-62
2.X,Y and R angle adopted micrometer fine-tuning,accuracy locating,precision can reach ±0.01mm. zm-62
Superior safety protection function
With the alarm function, after the BGA welding the machine can alarm by the case of temperature abuse, the circuit can power off automatically with the double over-temperature protection.Temperature parameter having password protection to prevent any modification.WDS-620 BGA rework station Video link:
