| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Guangdong in China |
Quick Details
- Special Features: Waterproof / Weatherproof
- Technology: Infrared
- Sensor: CCD
- Type: Analog Camera
- Brand Name: Alersec
- Style: Mini Camera
- Model Number: AL-M06-700
Specifications
| Specification: | Dual camera with one body Mini vehicle wide view camera | ||
|
Features |
- Dual camera with one body Mini vehicle wide view camera; It can record in the front of car(outside) and inside at the same time; Special design for Taxi inside use. Horizontal view angle:130 degree,can synchronous take driver and passenger's video recording; Excellent night-vision,clear image,little noise When IR light is ON,it won't have infrared visible line,so that won't distract driver's sight, so it can be safe driving. 1/3 for SONY CCD,700TVL,2.1mm lens(130 degree),2.5mm lens(120 degree). |
||
| Model | M06 | ||
| Image Sensor | 1/3" for SONY Super HAD CCD | ||
| Synchronization | INT | ||
| Scanning | 2:1 Interlace | ||
| Horizontal Resolution | 700TVL | ||
| Horizontal angle | 130 degree(wide view) | ||
| IR LED | 10pcs8 IR 940nm LED | ||
| IR Distance | 5m | ||
| Mini CMOS(inside back bracket) | High-resolution CMOS, 6mm lens | ||
| Minimum Illumination | 0Lux(IR ON) | ||
| Gamma modification | 0.45 | ||
| Gain control | Auto | ||
| White Balance | Auto | ||
| Electronic shutter | 1/60(1/50)~1/100,000 sec | ||
| Video output | 1.0Vp-p Composite Video Output,75ohm | ||
| Lens | 2.1mm | ||
| S/N Ratio | More than 48dB | ||
| Operational Voltage | DC12V | ||
| Operational Temperature | (- 25~+85) | ||
| Application use | Vehicle include taxi, bus, car inside use. | ||
| Body size | 126x30x100mm | ||
