PVC Coated Surface Treatment and Low Carbon Steel Wire Material Barbed Wire Machine

FOB Price:	5,000.00 - 10,000.00 USD/Set
Supply Ability:	20 Set/Sets per Month
Shipping:	15days after receiving the down payment
Payment Terms:	L/C, T/T

In Stock

Inquiry Now

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Hebei in China
Packaging Details:	Packing: pallet ,polybag or as your require,woodencase for PLC and other easy damaged parts or as yo

Quick Details

After-sales Service Provided: Engineers available to service machinery overseas
Model Number: SK-BA
Brand Name: SECURE-NET
Machine name: barbed wire machine
Strand diameter: 2.2-2.8mm
Wire diameter: 1.8-2.2mm
Barb pitch spacing: 76mm,102mm
Twist: 4
Rated output: 70kg/h
Motor: 3kw
Rotating speed of drive shaft: 432r/min
Wire connecting part size: 1800X750X750mm
Weight: 1500kg

Specifications

CS-A Normal Double twisted Barbed Wire Machine

CS-A double twisted barbed wire machine is designed to produce screens with single or

double-strand barbed steel wire, thermo-plated with zinc.

The machine is of horizontal design, consisting of two parts,

assembled together at the middle. It is safe and reliable in operation,

capable of turnning out high quality products with consistency.

Item
Motor	3kw
Rated output	70kg/h
Weight	1500kg
Overall Dimension	1900mmx1300mmx980mm
Wire collection part size	1800mmx750mmx750mm
Barb pitch spacing	76mm 102mm
Twist	4
Strand Diameter	1.8-3.0mm
Wire Diameter	1.7-2.8mm
Rotating Speed of Drive shaft	432r/min

CS-B single twisted Barbed Wire Machine

CS-B single twisted Barbed Wire Machine is designed to produce screens with single

stranded barbed steel wire , thermo-plated with zinc. The machine is of horizontal design,

consisting of two parts , assembled together at the middle. It is safe and reliable in operation, capable of turning out high quality products with consistency.

Item
Motor	2.2kw
Rated output	50kg/h
Weight	1200kg
Overall Dimension	1900mmx1300mmx980mm
Wire collection part size	1300mmx800mmx700mm
Barb pitch spacing	As required
Twist	4,6
Strand Diameter	1.6-2.6mm
Wire Diameter	1.6-2.2mm
Rotating Speed of Drive shaft	357r/min

CS-C Normal and Reverse Barbed Wire Machine

CS-C Normal and Reverse Barbed Wire Machine Barbed Wire Machine for Two-strand Wire with Two-way Twists can produce the barbed wire with two-way twists. This way is easy to operate and install as they will not entwist each other.

Item
Motor	2.2kw
Rated output	40kg/h
Weight	1200kg
Overall Dimension	1900mmx1300mmx980mm
Wire collection part size	1300mmx800mmx700mm
Barb pitch spacing	76mm 102mm
Twist	4
Strand Diameter	1.6-2.8mm
Wire Diameter	1.6-2.2mm
Rotating Speed of Drive shaft	432r/min

Packing: pallet , polybag or as your require, woodencase for PLC and other easy damaged parts or as yourspecial request
