Wch Cable Industrial Co., Ltd.

China Manufacturer with main products: Spiral Cable, PUR Cable, LSZH Cable, TPU Cable, Spring Cable, Curly Cable, Curly Cord, Coil Cable

Home  >Products Catalog > TPU Cable > UL20280 Polyurethane Cable (PUR/TPU) 80C 300V

UL20280 Polyurethane Cable (PUR/TPU) 80C 300V

FOB Price: 0.05 - 0.35 USD/Meter
Supply Ability: 3,000,000 Meter per Month
Shipping: 7 days to 14 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
In Stock
Export Markets: North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin: Guangdong in China
Packaging Details: 305 meters per roll

Quick Details

  • Jacket: PUR
  • Conductor Material: Copper
  • Application: Instrumentation
  • Model Number: WCH-20280
  • Brand Name: WCH Cable
  • UL Style Number: UL20280

Specifications

Product Description:

1. Tinned, annealed, stranded or solid pure copper conductor.

2. Insulation material: PE, HDPE, PVC, SR-PVC, PP, TPE, TPEE (optional)

3. Rated temperature: 80.

4. Rated voltage: 300V.

5. Uniform insulation wall thickness for easy stripping and cutting.

6. UL VW-1 and CSA FT-1/FT-2 vertical flame test verified.

7. Screen: tinned or bare copper spiral shielded or braided.

8. Bundle of cores is to be isolated by cotton paper, aluminum foil or mylar.

9. Jacket material: Extruded Polyurethane / TPU / PUR

10. Standard executed: UL758, UL1581, CSA22.2

11. 100% RoHS compliant.

12. UL style number: UL20280



Application:

For Internal wiring or external interconnection of electronic equipment.

Cores

Conductor

Overall
Diameter

No.

AWG

No/mm

mm

3C

30

7/0.100

3.80

28

7/0.127

4.00

26

7/0.16

4.20

24

11/0.16

4.50

22

17/0.16

5.00

20

21/0.178

5.40

18

34/0.178

6.00
