Welded Wire Mesh Machine Details
| FOB Price: | 3,000.00 - 10,000.00 USD/Set |
|---|---|
| Supply Ability: | 5 Set/Sets per Month |
| Shipping: | 30days |
| Payment Terms: | L/C, T/T, D/A, D/P, MoneyGram |
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Hebei in China |
| Packaging Details: | main machine:plastic bags electric cabinet:wooden boxes |
Quick Details
- Type: Welding Wire Machine
- After-sales Service Provided: Engineers available to service machinery overseas
- Certification: ISO9001:2008
- Weight: 3500kgs
- Dimensions: 8000x3200x2000
- Rated Capacity: 65x2kva
- Voltage: 380v 50hz
- Usage: Automatic Building Steel Wire Mesh
- Model Number: SK-1200
- Brand Name: SECURE-NET
- Condition: New
- wire diameter: 1.4-2.5mm
- opening size: 50-200mm
- welding width: 1200mm
- name: 1.4-2.5 Automatic Building Steel Wire Mesh Welding Machine
- machine size: 8000x3200x2000
- machine weight: 3500kgs
- welding spot: 25
Specifications
1.4-2.5 Automatic Building Steel Wire Mesh Welding Machine
The main parameter:
Wire diameter: 1.4-2.5mm
Welding aperture: 50*50-200*200mm
Width of mesh: 1200mm(adjustable)
Rated voltage: AC380V 50HZ(customized)
Number of electrodes: 25(adjustable)
Welding speed: 60times/min
Machine weight: 2.5T
Overall dimension: 2.5*2.5*1.5m(customized)
Product description :
1. This machine adopts electrical synchronous control technique both separate-phase welding and welding time is composed of digital and integrated electric circuit. This operation is accurate, it is stable, firm welded spot is firm and without weled tracks.
2. The cross and line wires are fed from coils.
3. This machine is equipped with precise equipment for weft cutting and position, so the length of wefts is identical and regular, it is unnecessary to slice the side.
4. Mesh pulling system adopts elastic tension link and openig positioning device, it is easy to regulate the mesh hole and mesh opening size is rather accurate, welding aperture could adjust randomly with range. Not only welding speed is fast but also it is easy to learn and operate.
5. The finished product can be in coil or in panel.
