Shanghai Chenfei Machinery Technology Co., Ltd.
China Manufacturer with main products: Apple/Pear Processing Line, Peach/Apricot/Plum Processing Line, Mango/Pineapple Processing Line, Coconut Processing Line, Transformation of... |
Tomato paste filling machine
| FOB Price: | 3,000.00 - 5,000.00 USD/Set |
|---|---|
| Supply Ability: | 100 Set/Sets per Month |
| Shipping: | ocean transportation |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Jiangsu in China |
| Packaging Details: | wooden case for export |
Quick Details
- Type: Filling Machine
- After-sales Service Provided: Engineers available to service machinery overseas
- Dimension(L*W*H): 2500*2000*2500
- Model Number: CFM-GZJ01
- Brand Name: Chenfei Machinery
- Power: 1kw
- Driven Type: Electric
- Automatic Grade: Automatic
- Packaging Material: aseptic bag
- Packaging Type: Bags
- Application: Beverage,Food
- Condition: New
Specifications
Application:
widely used in aseptic packaging of fruit juice, fruit pulp and jam and other liquid food.
Characteristics:
Automatic
aseptic filling machine is specially designed for large capacity filling. It occupies
less areas, works stably and operates conveniently. Using Aseptic filling
machine Food can be stored for more than one year at room temperature, which
reduces the low temperature refrigerating transportation costs and
risks.(concentrated juice and jam can be saved for more than 2 years at room
temperature.)
Aseptic filling machine can be directly
connected to the sterilizer, direct filling the product after UHT sterilization
into the aseptic bags. Aseptic aluminum plastic compound multi-layer bags can
effectively isolate sunshine and oxygen and maximize the guarantee product
quality.
Temperature control system automatically
adjusts the room temperature and the steam jet method is used for the sterilization
for the bag mouth and filling room.
Structure:
1. The filling head (single or double)
2. High precision electronic scale/mass
flowmeter
3. The control cabinet, stainless steel
electric components and touch screen HMI in electric control cabinet
4. The roller conveyor
Features:
1. The
main structure is SUS304 stainless steel material
2. Provide a wide range of security measures
(position control, measuring control, temperature control), to prevent the
mechanical damage
3. The mirror surface welding technology
ensures smooth welding and reduces product residues
4. The product valve and filling head movement
part adopts steam barrier protection, filling chamber adopts steam
sterilization
5. Adopt programmable controller to realize
automatic equipment operation
Technical Parameter:
|
Model |
CFM-GZJ-1(Single-head) |
CFM-GZJ-2 (Double-head) |
|
Capacity(L/H) |
1000-3000 |
4000-8000 |
|
Power(kw) |
1 |
1 |
|
Steam Consumption(0.1mpa)(kg/h) |
20 |
40 |
|
Condensed Air Consumption(8kg/cm2) |
20 |
40 |
|
Max Weighing Range(kg) |
2000 |
2000 |
|
Weighing Tolerance |
±1% |
±1% |
|
Machine size(mm) |
2500*2000*2500 |
3700*2000*2500 |
