Computer Control Electronic Universal Testing Machine (Single Space)

FOB Price:	1.00 USD/Set
Supply Ability:	360 Set(s) per Year
Payment Terms:	L/C, D/A, D/P, T/T

In Stock

Inquiry Now

Related products from verified members

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Shandong in China

Quick Details

Usage: Universal Testing Machine
Power: Electronic
Model Number: WDW-D200/300
Brand Name: HRJ

Specifications

Computer Control Electronic Universal Testing Machine Single Space

Technical Specification
1) max. Load capacity: 200kN/300kN;
2) measuring range of load: 0.4%-100%FS;
3) load accuracy: better than ±0.5%;
4) load resolution: 1/±300000F.S (with constant resolution along the whole stroke);
5) measuring range of deformation: 0.2%-100%FS;
6) adjusting range of control rate of load: 0.005-5%FS/s;
7) adjusting range of deformation rate: 0.005-5%FS/s;
8) adjusting range of displacement rate: 0.001-500mm/min;
9) max. Stroke of cross beam(excludes the fixtures): 1200mm
10) effective test space: 610mm
11) power supply(with grounded protective measures): 380V±10%, 50Hz
12) power: 5kw
13) dimension (L*W*H): 1050*750*2600 (mm)

Material

Lamina, board, strip, foil (aluminum foil, tin foil), sheet, steel bar, flat bar, wire(wire rod, iron wire, steel wire), stick, proximate matter, tubular product(tube, pipe), thin metal, silk thread(silk yarn), filament, fiber, elastomer, foam, cast iron, cast iron alloy, tube section, proportion specimen, non-proportion specimen, film, textile, rubber, plastic, thin film, biological material, electronic components, printed circuit board, wood work(wood ware, wooden product, wooden articles), paper product.

Shape:

Round(circular), square, rectangle(orthogon), circular ring.

Standards:
ISO 6892-1:2009.MOD
ASTM E 8M-08.Standard Test Methods for Tension Testing of Metallic Materials[Metric]

BS EN10002-1:2001

ISO 7348:2005.MOD

ASTM E9-89a(2000).Standard Test Methods of Compression Testing of Metallic Materials at Room Temperature

ISO 23718:2007.MOD
