Middle-high speed Electronic Universal Testing Machine
| Supply Ability: | 360 Set/Sets per Year |
|---|---|
| Shipping: | Tianjin |
| Payment Terms: | L/C, D/A, D/P, T/T |
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Shandong in China |
| Packaging Details: | wooden case |
Quick Details
- Usage: Universal Testing Machine
- Power: Electronic
- Model Number: ETM-D200/300
- Brand Name: HRJ
Specifications
Introduction
1. mechanical property testing and researching by tensile, compression, bending, torsion, shearing test for metal, nonmetal, composite material by room temperature.
2. sheet, board, belt, foil, flat bar, wire, bar, proximate matter, pipe, shape of square, rectangle and ring, cast iron, non-titanium alloy, tube section specimen, proportion specimen(proportion factor k=11.3 or 5.65), non-proportion specimen, total wall thickness longitudinal and crosswise splited specimen, rectangle cross-section sample, round cross-section sample.
3. test with variety of metal sheet, wire, thin thread, fiber, elastomer, foam.
4. textile, food, medicine, cosmetic, rubber, plastic, thin film, biological material.
5. tensile, peeling and welding test with eletronic element.
6. test for peeling, bending and fastener property with printing circuit board.
7. tensile test with wood, paper and film product.
8. stress relaxation test and adhesive bonding test.
Important specification:
|
ETM-D200, ETM-D300, 200kN/300kN Middle-High speed Testing Machine/Double Column System |
||
|
1 |
Loading capacity |
200kN/300kN |
|
2 |
Precision of loading |
±0.5, ±1.0 |
|
3 |
measuring range of loading |
0.4%～100%F.S, 1.0%～100%F.S |
|
4 |
gathering frequency |
500Hz |
|
5 |
resolution of loading |
1/±300000F.S(resolution of full scale is not changed ) |
|
6 |
measuring range of deformation |
0.2%～100% |
|
7 |
relative error of indicating value for deformation |
between ±0.5% of indicating value |
|
8 |
resolution of deformation |
1/±300000 of Max. derformation; |
|
9 |
resolution of displacement |
0.015μm |
|
10 |
adjusting range of loading speed |
0.005～5%F.S/S |
|
11 |
adjusting range of stress speed |
0.02～5%F.S/S |
|
12 |
adjusting range of speed of transom |
0.001～700mm/min(28in/min) |
|
13 |
effective testing space |
610mm |
|
14 |
moving stroke of transom |
1200mm |
|
15 |
rate of machine |
5kW |
|
16 |
voltage of power |
～380V±10% 50Hz(reliable grounding) |
