Slow Strain Speed and Stress Corrosion Testing Machine
| Supply Ability: | 360 Set/Sets per Year |
|---|---|
| Shipping: | Tianjin |
| Payment Terms: | L/C, D/A, D/P, T/T |
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Shandong in China |
| Packaging Details: | wooden case |
Quick Details
- Usage: Universal Testing Machine
- Power: Electronic
- Model Number: SSRT-10/20/50/100
- Brand Name: HRJ
Specifications
Introduction
1. testing and researching by constant speed test, lasting tensile test, constant loading creep test, corrosion fatigue test, corrosion stressd fracture compression test, corrosion crack growing test, crack extending test for material, component, part and metal, nonmetal, composite and alloy material under lasting stress and corrosion medium.
2. it is suitable for metal, pipe, component, (casing pipe, oil pipe, casing pipe of flat end, screened pipe, short joint, welding steel pipe, seamless steel pipe, underground pipe, condencer pipe, brass, alumnium alloy, stainless steel, steel, steel rope, high pressure gas cylinder, steel cylinder)
3. simulation environment(transport gas and oil, drilling well, loging well, repairing well, layer cracking, ocean, aviation, underground, mine.)
4. corrosion fatigue test, slow strain speed test, sulfide stess corrosion test, stress corrosion test, hydrogen induced cracking, slow strain speed and stress corrosion test, stress guiding hydrogen induced cracking test, metal average corrosion test for total immersion, anti-corrosion porterty test, electro corrosion test, intergranular corrosion test, crevice corrosion test, galvanic corrosion test
important specification
|
SSRT series, 10kN/20kN/50kN/100kN Slow Strain Rate Stress Corrosion Testing Machine Slow Tension Stress corrosion Testing Machine |
|||||
|
1 |
Max. loading |
10kN/20kN |
30kN/50kN |
100kN |
|
|
2 |
Grade of testing machine |
Grade of 0.5 / 1 |
|||
|
3 |
measuring range of loading |
0.4%～100%FS(grade of 0.5)/1%～100%FS(grade of1) |
|||
|
4 |
relative error of indicating value |
Between ±0.5%(grade of 0.5)/±1.0%(grade of 1) |
|||
|
5 |
resolution of loading |
1/±300000FS(resolution is not changed in full stroke) |
|||
|
6 |
Measuring range of deformation |
0.2%～100% FS |
|||
|
7 |
adjusting range of loading speed |
0.005%～5%FS/S |
|||
|
8 |
control precision of loading speed |
When speed is ＜0.05%FS, between ±1% of set value, When speed is 05%FS, between ±0.5% of set value |
|||
|
9 |
adjusting range of deformation speed |
0.005～5%FS/s |
|||
|
10 |
control precision of deformation speed |
When speed is ＜0.05%FS/s, between ±1% of set value When speed is ≥0.05%FS/s, between ±0.5% of set value |
|||
|
11 |
adjust range of displacement speed |
10-7～2mm/min |
|||
|
12 |
control precision of displacement speed |
Between ±0.2% of set value |
|||
|
13 |
control range of constant loading,deformation, displacement |
0.5%～100%FS |
|||
|
14 |
control precision fo constant loading, deformation and displacement |
When set value is ≥10%FS, between±0.5% of set value When set value is ＜10%FS, between ±1% of set value |
|||
|
15 |
effective test span |
400mm |
400mm |
500mm |
|
|
16 |
moving stroke of transom |
1000mm |
1000mm |
1200mm |
|
|
17 |
stress corrosion environmental container |
Anti–high temperature /sealing fully/prevention of leaking/prevention of volatilizing/temperature indicating/test for longtime/ high temperature300° |
|||
|
18 |
Rapid adjusting device |
Test space of rapid adjusting |
|||
|
19 |
Voltage of power |
～220V±10% 50Hz (reliable landing) |
|||
|
20 |
rate of machine |
400W |
750W |
2000W |
|
|
21 |
size of loading frame(LWH) |
860x460x1750mm |
940x520x1850mm |
1050x560x2150mm |
|
|
22 |
weight |
≈350kg |
≈550kg |
≈850kg |
|
