Yokogawa EJA510A and EJA530A Absolute and Gauge PressureTransmitters

Specifications

 Yokogawa EJA510A and EJA530A Absolute and Gauge PressureTransmitters

Unit price : 500-870 USD       Min Order : 1 piece
Payment Terms:L/C, T/T, Western Union .
Delivery time : 2-3weeks

Transmitter Specifications:

Output:
Two wire 4 to 20 mA DC output with digital communications.
BRAIN or HART FSK protocol are superimposed on the 4 to 20 mA signal

Stability :

0.1% of URL per 12 months

Degrees of Protection :
IP67, NEMA4X

Housing :
Low copper cast-aluminum alloy with polyurethane
paint (Munsell 0.6GY3.1/2.0)

Mounting Position Effect :
Rotation in diaphragm plane has no effect. Tilting up
to 90 will cause zero shift up to 0.27 kPa {1.1 inH2O}
which can be corrected by the zero adjustment

Supply Voltage :
10.5 to 42 V DC for general use and flameproof type
10.5 to 32 V DC for lightning protector (Optional
code /A)
10.5 to 30 V DC for intrinsically safe, Type n,
nonincendive, or non-sparking type
Minimum voltage limited at 16.4 V DC for digital
communications, BRAIN and HART

Basic Information :
Diaphragm seals are used to prevent process medium form entering directly into the pressure-sensing assembly of the
differential pressure transmitter, they are connected to the transmitter using capillaries filled with fill fluid.
Model EJA118W, EJA118N and EJA118Y Diaphragm Sealed Differential Pressure Transmitters can be used to
measure liquid, gas, or steam flow, as well as liquid level,density, and pressure. They output a 4 to 20 mA DC signal
corresponding to the measured pressure differential.
The transmitters also feature remote setup and monitoring through communications with the model BT200/100 BRAIN
TERMINAL, CENTUM CS/XL system etc.

Model:
1. EJA110A Differential pressure transmitter
2. EJA120A Differential pressure transmitter
3. EJA130A High Static pressure transmitter
4. EJA210A,220A Flange installation type differential pressure transmitter.
5. EJA310A Absolute pressure transmitter
6. EJA430A Pressure transmitter
7. EJA440A High pressure transmitter 30A Absolute pressure/pressure transmitter.
8. EJA118W,N,Y Diaphragm seal type differential pressure transmitter
9. EJA115 Tiny flow transmitter
10. EJA213,233 Health type liquid level transmitter.
11. EJA113W Health type diaphragm sealed differential pressure transmitter
12. EJA433W Health type diaphragm sealed pressure transmitter
13.EJA510A EJA530A Pressure transmitter
14. EJA series HART communication transmitter.
