Jinan Heng Rui Jin Testing Machine Co., Ltd.
China Manufacturer with main products: Electronic Universal Testing Machine, Tensile Testing Machine, Hydraulic Universal Testing Machine, Compressing Testing Machine, Torsion... |
Home
>Products Catalog > electronic universal testing mchine > Digital Display Electronic Tensile Testing Machine (Single Space)(Cantilever)
Digital Display Electronic Tensile Testing Machine (Single Space)(Cantilever)
| FOB Price: | 1.00 - 2.00 USD/Set |
|---|---|
| Supply Ability: | 360 Set(s) per Year |
| Shipping: | Tianjin |
| Payment Terms: | L/C, D/A, D/P, T/T |
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Shandong in China |
| Packaging Details: | wooden case |
Quick Details
- Usage: Universal Testing Machine
- Power: Electronic
- Model Number: WDS-XD
- Brand Name: HRJ
Specifications
Introduction
1 tensile, compression and bending test with variety of rubber, plastic, film, nonmetal material, and composite material.
2 test with variety of metal, thin metal, wire, fine wire, fiber, elastomer, foam
3 test with textile, food, medcine, cosmetic, and biology material.
4 tension, peeling, welding strength of electronic component.
5 peeling, bending, fastening property with printing circuit board.
6 test with production made of wood, paper, film.
Important specification
WDS-XD 50 100 200 500 1000 2000 3000 5000
1
Max. Loading force
50N
100N
200N
500N
1000N
2000N
3000N
5000N
2
Grade of testing machine
Grade 1/0.5
3
Measure range of loading
1%～100%FS
4
Relative error of indicating value
between ±1.0%(grade1)/±0.5%(grade 0.5)
5
Resolution of loading
0.01N
6
Resolution of deformation
0.01mm
7
Adjusting range of force controlled speed
0.005%-5%FS/S
8
Control precision of force controlled speed
When speed is <0.05%FS, between ±1% of setting value
When speed is ≥0.05%FS, between ±0.5% of setting value
9
Adjusting range of speed for deformation
0.00--5%FS/s
10
Control precision of speed for deformation
When speed is ＜0.05%FS/s, between ±1% of setting value,
When speed is ≥0.05%FS/s, between ±0.5% of setting value
11
Adjusting range of speed for displacment
0.2～500mm/min; (customized high speed system: 0.001-1500mm/min)
12
Control precision of speed for displacement
between ±1.0% of setting value
13
Loading mode
Computer auto control
14
Moving stroke of transom
1000mm / 1200mm / 1400mm
15
Measure range of large deformation
10-800mm / 1000mm / 1200mm
16
Voltage
～220V±10% 50Hz(reliable landing)
17
Rate
400w
