LCD Geotextile Testing Machine

Inquiry Now

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Shandong in China
Packaging Details:	wooden case

Quick Details

1 tension, compression, bending test with variety of rubber, plastic, thin film, metal and nonmetal material.

2 test with variety of metal, thin metal, wire, fine wire, fiber, elastomer, foam.

3 test with textile, food, medicine, cosmetic, biology material.

4 tensile, peeling, welding strength test with electronic element.

5 test for peeling, bending, fasten property with printing circuit board.

6 test with product made of wood, paper, film and other nonmetal material.

important specification

WDS-T series 5kN 10kN 20kN 30kN 50kN 100kN
1	Max. loading	5kN/10kN		20kN		30kN/50kN		100kN
2	grade of testing machine	Grade 0.5/1
3	measure range of loading	0.4%-100%FS (grade0.5)/1%～100%FS(grade 1)
4	relative error of indicating value	Between ±0.5% (grade 0.5) /±1.0%(grade 1)
5	resolution of loading	0.01N
6	resolution of deformation	0.01mm
7	adjusting range of force controlled speed	0.005%-5%FS/S
8	control precision of force controlled speed	When speed is <0.05%FS, between ±1% of setting value When speed is ≥0.05%FS, between ±0.5% of setting value
9	adjusting range of speed for deformation	0.005～5%FS/s;
10	control precision of speed for deformation	When speed is <0.05%FS/s, between ±1% of setting value When speed is ≥0.05%FS/s, between ±0.5% of setting value
11	adjusting range of speed for displacement	0.2～500mm/min (customized high speed system:0.001-2000mm/min)
12	control precision of speed for displacement	between ±1.0% of setting value
13	Loading mode	computer auto control
14	effective test span	400mm					500mm
15	moving stroke of transom	1000mm					1200mm
16	Power	～220V±10% 50Hz(reliable landing)
17	rate	400w			750W		1500w
18	Size of frame(LWH)mm	6604151780	7304101680		7555201780		8505551900
19	weight	≈200kg	≈260kg		≈410kg		≈700kg
