LCD Electronic Universal Testing Machine
| Supply Ability: | 360 Set/Sets per Year |
|---|---|
| Shipping: | Tianjin |
| Payment Terms: | L/C, D/A, D/P, T/T |
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Shandong in China |
| Packaging Details: | wooden case |
Quick Details
- Usage: Universal Testing Machine
- Power: Electronic
- Model Number: WDW-S 1/2/5/10/20/30/50/100
- Brand Name: HRJ
Specifications
Introduction
1 tensile, compression and bending test with variety of rubber, plastic, film, nonmetal material, and composite material.
2 test with variety of metal, thin metal, wire, fine wire, fiber, elastomer, foam
3 test with textile, food, medcine, cosmetic, and biology material.
4 tension, peeling, welding strength of electronic component.
5 peeling, bending, fastening property with printing circuit board.
6 test with production made of wood, paper, film.
Important specification
|
WDW-S 1kN 2kN 5kN 10kN 20kN 30kN 50kN 100kN |
||||||||
|
1 |
Max. loading |
1/2/5/10kN |
20kN |
30kN/50kN |
100kN |
|||
|
2 |
grade of machine |
Grade of 0.5 / 1 |
||||||
|
3 |
measure range of loading |
0.4%-100%FS(grade 0.5) /1%~100%FS(grade 1) |
||||||
|
4 |
relative error of indicating value |
Between ±0.5%(grade 0.5) /±1.0% (grade 1) |
||||||
|
5 |
resolution of loading |
0.01N |
||||||
|
6 |
resolution of deformation |
0.01mm |
||||||
|
7 |
adjusting range of speed for loading |
0.005%-5%FS/S |
||||||
|
8 |
control precision of speed for loading |
When speed is <0.05%FS, between±1% of setting value When speed is ≥0.05%FS, between±0.5% of setting value |
||||||
|
9 |
adjusting range of speed for deformation |
0.005~5%FS/s |
||||||
|
10 |
control precision of speed for deformation |
When speed is ＜0.05%FS/s, between ±1% of setting value When speed is ≥0.05%FS/s, between ±0.5% of setting value |
||||||
|
11 |
adjudsting range of speed for displacement |
0.2~500mm/min; (customized high speed system :0.001-2000mm/min) |
||||||
|
12 |
control precision of speed for displacement |
Between ±1.0% of setting value |
||||||
|
13 |
Loading mode |
Computer auto-control |
||||||
|
14 |
effective test span |
400mm |
500mm |
|||||
|
15 |
moving stroke of transom |
1000mm |
1200mm |
|||||
|
16 |
voltage |
~220V±10% 50Hz (reliable landing) |
||||||
|
17 |
rate |
400w |
750W |
1500w |
||||
|
18 |
size(LWH)mm |
660*415*1780 |
730*410*1680 |
755*520*1780 |
850*555*1900 |
|||
|
19 |
weight |
≈200kg |
≈260kg |
≈410kg |
≈700kg |
|||
