Liaoyang Pharma Machinery Co., Ltd.

China Manufacturer with main products: Tea Bag Packing Machine and Filter Tobacco Packaging Machine, Milk Powder Pacaking Machine, Granulated Sugar Packaging Machine, Liquid...

Home >Products Catalog > Chocolate/Honey/Butter ALU/PVC Blister Packing Machine

Chocolate/Honey/Butter ALU/PVC Blister Packing Machine

FOB Price:	8,500.00 - 10,000.00 USD/Set
Payment Terms:	L/C, T/T, Western Union, MoneyGram

In Stock

Inquiry Now

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe

Quick Details

Type: Blister Packaging Machine
After-sales Service Provided: Engineers available to service machinery overseas
Warranty: 1 year
Certification: CE, ISO
Weight: 480
Dimension(L*W*H): 1840x590x1100
Model Number: LPDPB80
Brand Name: KVN
Power: 2.8KW
Voltage: 220V
Driven Type: Electric
Automatic Grade: Automatic
Application: Food
Condition: New

Specifications

It adopts the newest type high-power transmission mechanism to arrange the chain and drive the main driving shaft. The errors and noises of other gear wheel transmission can be avoided

Imported controlling system is adopted; also it can be equipped with detecting and rejection function device for number of medicines according to the user's requirement.

Technical Parameters:

Punch frequency	10-33times/min
Production capacity	2400plates/hour
Max. Forming area & Depth	105x70(standard depth ≦14mm), Max. Depth 25mm( Customized)
Standard Stroke range	30-80mm(can be designed as per user's required)
Standard plate size	80x70mm (can be designed as per user's required)
Air pressure	0.4-0.6Mpa
Compressed air required	Air compressor≥0.3m3/min
Total power supply	220V 50Hz 2.8Kw
Main motor	0.75Kw
PVC hard Film	0.15-0.5*110 (mm)
PTP Aluminum film	0.02-0.035*110 (mm)
Mould cooling	Tap water or Recycling water
Overall Dimension	0 (mm)(LxWxH)
Weight	Net 480kg Gross weight: 550kg
Noise index	<75dBA
