Flammability plastic tester IEC60695 Horizontal and vertical flammability tester

FOB Price:	1.00 USD/Set
Supply Ability:	800 Set(s) per Year
Shipping:	Flammability plastic tester IEC60695 Horizontal and vertical flammability tester
Payment Terms:	T/T

In Stock

Inquiry Now

Related products from verified members

Product Details

Export Markets:	North America, Eastern Europe, Southeast Asia, Mid East
Place of Origin:	Guangdong in China
Packaging Details:	Packed with strong wooden case

Quick Details

Power: Electronic
Model Number: AUTO-SPA
Brand Name: AUTOSTRONG
Standard: UL94,IEC60695-11-3,IEC60695-11-20
Power: Electronic
Usage: Flammability testing equipment
Warranty: 1Year
Thermocouple Size: 0.5 mm
Kinds: 500W(5V class ) and 50W(HB/Vclass)
Thermocouple: Type K (Ni/Cr - Ni/Al)

Specifications

Flammability plastic tester IEC60695 Horizontal and vertical flammability teste

Flammability chamber:
1.for plastics flammability test
2.Shenzhen Manufacturer, OEM offered
3.high quality hot sale

Product Description

1.Application:When there is a fire around the products, should ensure that it will not to cause the spread of the fire, horizontal-vertical burning test simulates electronic products around the environment in the early condition, using the simulation technology to assess the fire risk. The test equipment apply to the electrical and electronic product components of household appliances, spare parts and components, such as: household appliances insulation shell, Panel switches, printed circuit boards and insulation materials and so on.

2.Characteristics:Horizontal and vertical flammability chamber is composed by the test part and control part, using the integrated design, to facilitate the installation at the scene and debug. The shell of the test chamber and the important parts are all manufactured by stainless steel, resistant cigarettes and gas corrosion. The automatic degree of control system is high. Has automatic ignition, the products which were tested in both vertical and horizontal orientation has the function automatically follow flame in the cross of the test. Time and temperature figures show, so that the observation and records is facilitate and the use of it is stable and reliable.

Flammability plastic tester IEC60695 Horizontal and vertical flammability tester

3.Technical Paremeters

Kinds	500W(5V class )	50W(HB/Vclass)
Horizontal vertical burning tester	500W(burning test for V-0,V-1,V-2 classification)	50W(burning test for V-0,V-1,V-2 classification)
Burner Tube	Internal diameter: Φ 9.5mm±0.3mm	Internal diameter: Φ 9.5mm±0.3mm,
Burning Angle	0°,20°,45°	0°,20°,45 °
Thermocouple	Type K (Ni/Cr - Ni/Al)	Type K (Ni/Cr - Ni/Al)
Thermocouple Size	0.5 mm	0.5 mm
Standard Copper Block	Φ9mm±0.01mm, weight:10g±0.05g before drilling.	Φ5.5mm±0.01mm, weight.76g±0.01g before drilling.
Time for Temperature to Increase	From 100°C±5°C to 700°C±3°C; 54s±2s (preset)	From 100°C±5°C to 700°C±3°C; 44s±2s (preset)
Gas Flow	965±32ml/min	105±10ml/min
Gas Supply	methane,min.98% purity	methane,min.98% purity
water-column	125m±5mm	?10mm
Test Time	54±2s	44±2s
Flame Height Indicator	40±1mm	20±1mm
Volume Of Chamber	>0.5m3, black interior	>0.5m3, black interior
Conform to standard	UL94,IEC60695-11-3,IEC60695-11-20	UL94,IEC60695-11-4,IEC60695-11-10
